HCPL2631SDV Information
HCPL2631SDV by onsemi is an Optocoupler.
Optocoupler are under the broader part category of Optoelectronics.
Optoelectronic components work to detect, generate, and control light. They can essentially produce and/or react to light. Read more about Optoelectronics on our Optoelectronics part category page.
Price & Stock for HCPL2631SDV
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
82C4983
|
Newark | Transistor-Stage-Output Optocoupler,2-Channel,2.5Kv Isolation, so Rohs Compliant: Yes |Onsemi HCPL2631SDV RoHS: Compliant Min Qty: 1000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
Buy Now |
Part Details for HCPL2631SDV
HCPL2631SDV CAD Models
HCPL2631SDV Part Data Attributes
|
|
HCPL2631SDV
onsemi
Buy Now
Datasheet
|
Compare Parts:
HCPL2631SDV
onsemi
8-Pin DIP Dual-Channel High Speed 10 MBit/s Logic Gate Output Optocoupler (Not recommend for new design. The new equivalent part number is HCPL26xxM), PDIP-8 GW, 1000-REEL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | PDIP-8 GW | |
| Manufacturer Package Code | 709AF | |
| Reach Compliance Code | compliant | |
| HTS Code | 8541.40.80.00 | |
| Factory Lead Time | 23 Weeks | |
| Samacsys Manufacturer | onsemi | |
| Additional Feature | CMOS COMPATIBLE, OPEN COLLECTOR, UL RECOGNIZED, VDE APPROVED | |
| Configuration | SEPARATE, 2 CHANNELS | |
| Data Rate-Nom | 10 MBps | |
| Forward Current-Max | 0.03 A | |
| Isolation Voltage-Max | 2500 V | |
| JESD-609 Code | e3 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Elements | 2 | |
| Number of Functions | 2 | |
| On-State Current-Max | 0.05 A | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Optoelectronic Device Type | LOGIC IC OUTPUT OPTOCOUPLER | |
| Power Dissipation-Max | 0.06 W | |
| Response Time-Nom | 7.5e-8 ns | |
| Supply Voltage-Min | 4.5 V | |
| Supply Voltage-Nom | 5 V | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) - annealed |
