3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for FQU1N80TU by onsemi
Results Overview of FQU1N80TU by onsemi
- Distributor Offerings: (6 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (1 option)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
FQU1N80TU Information
FQU1N80TU by onsemi is a Power Field-Effect Transistor.
Power Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for FQU1N80TU
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
FQU1N80TU
|
Avnet Americas | Trans MOSFET N-CH 800V 1A 3-Pin(3+Tab) IPAK Rail - Rail/Tube (Alt: FQU1N80TU) RoHS: Compliant Min Qty: 1713 Package Multiple: 1 Lead time: 0 Weeks, 2 Days Container: Tube | 3772 Partner Stock |
|
$0.3435 / $0.3561 | Buy Now |
|
|
Rochester Electronics | Power Field-Effect Transistor, 1A, 800V, 20ohm, N-Channel, MOSFET, TO-251 RoHS: Compliant Status: Obsolete Min Qty: 1 | 539 |
|
$0.3093 / $0.4989 | Buy Now |
|
DISTI #
FQU1N80TU
|
TME | Transistor: N-MOSFET, unipolar, 800V, 630mA, Idm: 4A, 45W, IPAK Min Qty: 1 | 0 |
|
$0.4600 / $1.0010 | RFQ |
|
DISTI #
FQU1N80TU
|
Avnet Silica | Trans MOSFET NCH 800V 1A 3Pin3Tab IPAK Rail (Alt: FQU1N80TU) RoHS: Compliant Min Qty: 5040 Package Multiple: 70 Lead time: 143 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
DISTI #
FQU1N80TU
|
EBV Elektronik | Trans MOSFET NCH 800V 1A 3Pin3Tab IPAK Rail (Alt: FQU1N80TU) RoHS: Compliant Min Qty: 70 Package Multiple: 70 Lead time: 143 Weeks, 0 Days | EBV - 0 |
|
Buy Now | |
|
|
Flip Electronics | Stock, ship today | 3772 |
|
RFQ |
Part Details for FQU1N80TU
FQU1N80TU CAD Models
FQU1N80TU Part Data Attributes
|
|
FQU1N80TU
onsemi
Buy Now
Datasheet
|
Compare Parts:
FQU1N80TU
onsemi
Power MOSFET, N-Channel, QFET®, 800 V, 1.0 A, 20 Ω, IPAK, IPAK-3 / DPAK-3 STRAIGHT LEAD, 5040-TUBE
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | IPAK-3 / DPAK-3 STRAIGHT LEAD | |
| Package Description | IPAK-3 | |
| Manufacturer Package Code | 369AR | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 2 Days | |
| Samacsys Manufacturer | onsemi | |
| Avalanche Energy Rating (Eas) | 90 mJ | |
| Configuration | SINGLE WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 800 V | |
| Drain Current-Max (ID) | 1 A | |
| Drain-source On Resistance-Max | 20 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| JEDEC-95 Code | TO-251 | |
| JESD-30 Code | R-PSIP-T3 | |
| JESD-609 Code | e3 | |
| Number of Elements | 1 | |
| Number of Terminals | 3 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 150 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | IN-LINE | |
| Polarity/Channel Type | N-CHANNEL | |
| Power Dissipation-Max (Abs) | 45 W | |
| Pulsed Drain Current-Max (IDM) | 4 A | |
| Qualification Status | Not Qualified | |
| Surface Mount | NO | |
| Terminal Finish | MATTE TIN | |
| Terminal Form | THROUGH-HOLE | |
| Terminal Position | SINGLE | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON |
