ES3B-E3/57T Information
ES3B-E3/57T by Vishay Intertechnologies is a Rectifier Diode.
Rectifier Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for ES3B-E3/57T
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
79AH2390
|
Newark | 3A,100V,20Ns, uf Rect, Smd Rohs Compliant: Yes |Vishay ES3B-E3/57T RoHS: Compliant Min Qty: 850 Package Multiple: 1 Date Code: 0 Container: Reel | 11900 |
|
$0.1960 / $0.2520 | Buy Now |
|
DISTI #
96K9607
|
Newark | Rectifier Diode, Single, 100 V, 3 A, 900 Mv, 20 Ns, 100 A Rohs Compliant: Yes |Vishay ES3B-E3/57T RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 158 |
|
$0.4720 / $0.7860 | Buy Now |
|
DISTI #
76K4852
|
Newark | Fast Diode, 3A, 100V, Do-214Ab, Full Reel, Repetitive Peak Reverse Voltage:100V, Average Forward Current:3A, Diode Configuration:Single, Forward Voltage Max:900Mv, Reverse Recovery Time:20Ns, Forward Surge Current:100A Rohs Compliant: Yes |Vishay ES3B-E3/57T RoHS: Compliant Min Qty: 1700 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.1960 / $0.2520 | Buy Now |
|
DISTI #
ES3B-E3/57T
|
Avnet Americas | 3A,100V,20NS,UF Rect, SMC - Tape and Reel (Alt: ES3B-E3/57T) RoHS: Compliant Min Qty: 850 Package Multiple: 850 Lead time: 5 Weeks, 0 Days Container: Reel | 11900 |
|
$0.0873 / $0.0988 | Buy Now |
|
DISTI #
625-ES3B-E3
|
Mouser Electronics | Rectifiers 3.0 Amp 100V 20ns RoHS: Compliant | 2202 |
|
$0.1740 / $0.6300 | Buy Now |
|
DISTI #
E02:0323_00021263
|
Arrow Electronics | Diode Switching 100V 3A 2-Pin SMC T/R Min Qty: 850 Package Multiple: 850 Lead time: 5 Weeks Date Code: 2503 | Europe - 78200 |
|
$0.1325 / $0.1664 | Buy Now |
|
DISTI #
V36:1790_18773140
|
Arrow Electronics | Diode Switching 100V 3A 2-Pin SMC T/R Min Qty: 1700 Package Multiple: 1700 Lead time: 5 Weeks Date Code: 2408 | Americas - 18700 |
|
$0.0941 | Buy Now |
|
DISTI #
V72:2272_18773140
|
Arrow Electronics | Diode Switching 100V 3A 2-Pin SMC T/R Min Qty: 1 Package Multiple: 1 Lead time: 5 Weeks Date Code: 2132 Container: Cut Strips | Americas - 2931 |
|
$0.1008 / $0.3402 | Buy Now |
|
DISTI #
87543841
|
Verical | Diode Switching 100V 3A 2-Pin SMC T/R Min Qty: 850 Package Multiple: 850 Date Code: 2503 | Americas - 78200 |
|
$0.1980 / $0.2020 | Buy Now |
|
DISTI #
81324215
|
Verical | Diode Switching 100V 3A 2-Pin SMC T/R Min Qty: 1700 Package Multiple: 1700 Date Code: 2408 | Americas - 18700 |
|
$0.0941 | Buy Now |
Part Details for ES3B-E3/57T
ES3B-E3/57T CAD Models
ES3B-E3/57T Part Data Attributes
|
|
ES3B-E3/57T
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
ES3B-E3/57T
Vishay Intertechnologies
Rectifier Diode, 1 Phase, 1 Element, 3A, 100V V(RRM), Silicon, DO-214AB,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Reach Compliance Code | not_compliant | |
| Factory Lead Time | 5 Weeks | |
| Samacsys Manufacturer | Vishay | |
| Additional Feature | FREE WHEELING DIODE, LOW POWER LOSS | |
| Application | EFFICIENCY | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | RECTIFIER DIODE | |
| Forward Voltage-Max (VF) | 0.9 V | |
| JEDEC-95 Code | DO-214AB | |
| JESD-30 Code | R-PDSO-C2 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Non-rep Pk Forward Current-Max | 100 A | |
| Number of Elements | 1 | |
| Number of Phases | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -55 °C | |
| Output Current-Max | 3 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Rep Pk Reverse Voltage-Max | 100 V | |
| Reverse Current-Max | 10 µA | |
| Reverse Recovery Time-Max | 0.02 µs | |
| Reverse Test Voltage | 100 V | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | C BEND | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 |
