ECS-TXO-25CSMV-320-DY-TR Information
ECS-TXO-25CSMV-320-DY-TR by ECS International Inc is a TCXO.
TCXO are under the broader part category of Oscillators.
Oscillators are electronic components that produce sine or square waves in order to convert signals. Read more about Oscillators on our Oscillators part category page.
Price & Stock for ECS-TXO-25CSMV-320-DY-TR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
69AK8446
|
Newark | Tcxo, 32Mhz, Smd, 2.5Mm X 2Mm Rohs Compliant: Yes |Ecs Inc International ECS-TXO-25CSMV-320-DY-TR RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 916 |
|
$2.1500 / $2.6800 | Buy Now |
|
DISTI #
50-ECS-TXO-25CSMV-320-DY-CT-ND
|
DigiKey | XTAL OSC TCXO 32.0000MHZ CLPSNW Min Qty: 1 Lead time: 12 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
18278 In Stock |
|
$1.1670 / $2.0000 | Buy Now |
|
DISTI #
ECS-TXO-25CSMV-320-DY-TR
|
Avnet Americas | TCXO, Oscillator, 32 MHz, 2 ppm, SMD, 2.5mm x 2mm, Clipped Sinewave, 3.3 V, ECS-TXO-25CSMV - Tape and Reel (Alt: ECS-TXO-25CSMV-320-DY-TR) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 12 Weeks, 0 Days Container: Reel | 0 |
|
$1.0961 / $1.4821 | Buy Now |
|
DISTI #
520-TXO25CSMV320DYTR
|
Mouser Electronics | TCXO Oscillators MultiVolt TCXO,32MHz,+/-2ppm,1.7V 3.465V,2mA,-30 C 85 C, 2.50mm x 2.00mm RoHS: Compliant | 2661 |
|
$1.2000 / $2.0300 | Buy Now |
|
|
Onlinecomponents.com | Oscillator TCXO - 32MHz - 1.7V to 3.465V - 2.5mA - ±2ppm -30°C to 85°C - Clipped Sine Wave - 4-SMD - 0.098" x 0.079" (2.50mm x 2.00mm) RoHS: Compliant | 0 |
|
$1.1100 / $1.8400 | Buy Now |
|
DISTI #
ECS-TXO-25CSMV-320-DY-TR
|
IBS Electronics | ECS-TXO-25CSMV-320-DY-TR by ECS International is a high-precision crystal oscillator with a frequency of 32.0 MHz, low phase noise, and operates over a wide temperature range, ideal for communication systems. Min Qty: 1000 Package Multiple: 1 | 1000 |
|
$1.7030 | Buy Now |
|
DISTI #
ECS-TXO-25CSMV-320-DY-TR
|
Avnet Abacus | TCXO Oscillator 32 MHz 2 ppm SMD 25mm x 2mm Clipped Sinewave 33 V ECSTXO25CSMV - Tape and Reel (Alt: ECS-TXO-25CSMV-320-DY-TR) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 20 Weeks, 0 Days Container: Reel | Abacus - 0 |
|
Buy Now | |
|
|
New Advantage Corporation | RoHS: Compliant Min Qty: 1 Package Multiple: 1000 | 2000 |
|
$2.0200 / $2.1800 | Buy Now |
Part Details for ECS-TXO-25CSMV-320-DY-TR
ECS-TXO-25CSMV-320-DY-TR CAD Models
ECS-TXO-25CSMV-320-DY-TR Part Data Attributes
|
|
ECS-TXO-25CSMV-320-DY-TR
ECS International Inc
Buy Now
Datasheet
|
Compare Parts:
ECS-TXO-25CSMV-320-DY-TR
ECS International Inc
Clipped Sine Output Oscillator,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ECS INC INTERNATIONAL | |
| Package Description | SMD, 4 PIN | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 12 Weeks | |
| Samacsys Manufacturer | ECS | |
| Additional Feature | TR | |
| Aging | 1 PPM/FIRST YEAR | |
| Frequency Adjustment-Mechanical | NO | |
| Frequency Stability | 2% | |
| JESD-609 Code | e4 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 4 | |
| Operating Frequency-Nom | 32 MHz | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -30 °C | |
| Oscillator Type | CLIPPED SINE | |
| Output Impedance | 10000 Ω | |
| Output Level | 0.8 V | |
| Physical Dimension | 2.5mm x 2.0mm x 0.9mm | |
| Supply Voltage-Max | 3.465 V | |
| Supply Voltage-Min | 1.7 V | |
| Surface Mount | YES | |
| Terminal Finish | Gold (Au) |
