DRV5012AEDMRR Information
DRV5012AEDMRR by Texas Instruments is a Magnetic Field Sensor.
Magnetic Field Sensors are under the broader part category of Sensors/Transducers.
Sensors and transducers detect and measure physical quantities like temperature, pressure, and force, converting them into electrical signals for various applications. Read more about Sensors/Transducers on our Sensors/Transducers part category page.
Price & Stock for DRV5012AEDMRR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
296-48907-1-ND
|
DigiKey | MAGNETIC SWITCH LATCH 4X2SON Min Qty: 1 Lead time: 6 Weeks Container: Digi-Reel®, Tape & Reel (TR), Cut Tape (CT) |
9704 In Stock |
|
$0.2059 / $0.4200 | Buy Now |
|
DISTI #
595-DRV5012AEDMRR
|
Mouser Electronics | Board Mount Hall Effect / Magnetic Sensors UltraLowPowerDigital LatchHall EffectSen A 595-DRV5012AEDMRT RoHS: Compliant | 8096 |
|
$0.1330 / $0.2700 | Buy Now |
|
DISTI #
V72:2272_18665767
|
Arrow Electronics | Hall Effect Sensor 5mA Latch 1.8V/2.5V/3.3V/5V 4-Pin X2SON EP T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 6 Weeks Date Code: 2203 Container: Cut Strips | Americas - 649 |
|
$0.0784 / $0.1698 | Buy Now |
|
DISTI #
61309683
|
Verical | Hall Effect Sensor 5mA Latch 1.8V/2.5V/3.3V/5V 4-Pin X2SON EP T/R RoHS: Compliant Min Qty: 35 Package Multiple: 1 Date Code: 2203 | Americas - 649 |
|
$0.0784 / $0.1083 | Buy Now |
Part Details for DRV5012AEDMRR
DRV5012AEDMRR CAD Models
DRV5012AEDMRR Part Data Attributes
|
|
DRV5012AEDMRR
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
DRV5012AEDMRR
Texas Instruments
Low power (as low as 3.3-µA), low voltage (up to 5.5-V) Hall effect latch 4-X2SON -40 to 85
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Package Description | X2SON-4 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Date Of Intro | 2017-08-21 | |
| Samacsys Manufacturer | Texas Instruments | |
| Body Breadth | 1.1 mm | |
| Body Height | 0.4 mm | |
| Body Length or Diameter | 1.4 mm | |
| Housing | PLASTIC | |
| Hysteresis | 4 mT | |
| Input Mode | BIPOLAR(LATCHED) | |
| JESD-609 Code | e3 | |
| Magnetic Field Range-Max | 3.3 mT | |
| Magnetic Field Range-Min | -3.3 mT | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 4 | |
| Operating Current-Max | 0.37 mA | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output | PUSH-PULL | |
| Output Current-Max | 5 mA | |
| Output Polarity | COMPLEMENTARY | |
| Output Range | -5.0-5.0mA | |
| Output Type | DIGITAL CURRENT | |
| Package Shape/Style | RECTANGULAR | |
| Sensors/Transducers Type | MAGNETIC FIELD SENSOR,HALL EFFECT | |
| Supply Voltage-Max | 5.5 V | |
| Supply Voltage-Min | 1.65 V | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) | |
| Termination Type | SOLDER |
