3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for CFR25J6K8 by TE Connectivity
Results Overview of CFR25J6K8 by TE Connectivity
- Distributor Offerings: (10 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Consumer Electronics
Audio and Video Systems
Energy and Power Systems
Renewable Energy
Entertainment and Gaming
CFR25J6K8 Information
CFR25J6K8 by TE Connectivity is a Carbon Film Resistor.
Carbon Film Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for CFR25J6K8
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
95W5902
|
Newark | Through Hole Carbon Film Resistor, Cfr Series, 6.8 Kohm, 330 Mw, - 5%, 250 V, Axial Leaded Rohs Compliant: Yes |Neohm Te Connectivity CFR25J6K8 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk | 10 |
|
$0.0030 | Buy Now |
|
DISTI #
20R0715
|
Newark | Through Hole Carbon Film Resistor, Cfr Series, 6.8 Kohm, 330 Mw, - 5%, 250 V, Axial Leaded |Neohm Te Connectivity CFR25J6K8 RoHS: Not Compliant Min Qty: 12000 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
$0.0120 | Buy Now |
|
DISTI #
1712-CFR25J6K8CT-ND
|
DigiKey | RES 6.8K OHM 5% 1/3W AXIAL Min Qty: 1 Lead time: 17 Weeks Container: Cut Tape (CT), Tape & Box (TB) |
11650 In Stock |
|
$0.0101 / $0.1100 | Buy Now |
|
DISTI #
6-1623931-6
|
Avnet Americas | Resistor, 6.8 kOhm, ? 5%, 330 mW, Axial Leaded, Carbon Film, High Reliability - Bulk (Alt: 6-1623931-6) RoHS: Compliant Min Qty: 12000 Package Multiple: 12000 Lead time: 12 Weeks, 1 Days Container: Bulk | 0 |
|
$0.0090 / $0.0093 | Buy Now |
|
DISTI #
279-CFR25J6K8
|
Mouser Electronics | Carbon Film Resistors - Through Hole 6.8KOhm 1/3W 1200PPM RoHS: Compliant | 6777 |
|
$0.0130 / $0.1100 | Buy Now |
|
|
Onlinecomponents.com | Thin Film Resistor - 6.8 Kohm (+/-) 5% - 0.33W - 250V - Through Hole - -55°C to +155°C - Ammo Box RoHS: Compliant |
7900 Partner Stock |
|
$0.0093 / $0.0146 | Buy Now |
|
DISTI #
87169144
|
Verical | Res Carbon Film 6.8K Ohm 5% 0.33W(1/3W) -450ppm/°C to 0ppm/°C AXL Ammo RoHS: Compliant Min Qty: 4808 Package Multiple: 1 Date Code: 2017 | Americas - 6900 |
|
$0.0330 / $0.0389 | Buy Now |
|
DISTI #
27489525
|
Verical | Res Carbon Film 6.8K Ohm 5% 0.33W(1/3W) -450ppm/°C to 0ppm/°C AXL Ammo RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 | Americas - 4000 |
|
$0.0195 | Buy Now |
|
DISTI #
6-1623931-6
|
Avnet Abacus | Resistor 68 kOhm 5 330 mW Axial Leaded Carbon Film High Reliability (Alt: 6-1623931-6) RoHS: Compliant Min Qty: 12000 Package Multiple: 12000 Lead time: 17 Weeks, 0 Days | Abacus - 0 |
|
Buy Now | |
|
|
Master Electronics | Thin Film Resistor - 6.8 Kohm (+/-) 5% - 0.33W - 250V - Through Hole - -55°C to +155°C - Ammo Box RoHS: Compliant |
7900 Partner Stock |
|
$0.0093 / $0.0146 | Buy Now |
Part Details for CFR25J6K8
CFR25J6K8 CAD Models
CFR25J6K8 Part Data Attributes
|
|
CFR25J6K8
TE Connectivity
Buy Now
Datasheet
|
Compare Parts:
CFR25J6K8
TE Connectivity
Fixed Resistor, Carbon Film, 0.33W, 6800ohm, 250V, 5% +/-Tol, 450ppm/Cel, Through Hole Mount, AXIAL LEADED
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Transferred | |
| Ihs Manufacturer | TYCO ELECTRONICS COMPONENTS | |
| Package Description | AXIAL LEADED, ROHS COMPLIANT | |
| Reach Compliance Code | unknown | |
| ECCN Code | EAR99 | |
| HTS Code | 8533.10.00.65 | |
| Factory Lead Time | 12 Weeks, 1 Day | |
| Samacsys Manufacturer | TE Connectivity | |
| Manufacturer Series | CFR25 | |
| Mounting Feature | THROUGH HOLE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 155 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Shape | TUBULAR PACKAGE | |
| Packing Method | AMMO PACK | |
| Rated Power Dissipation (P) | 0.33 W | |
| Rated Temperature | 70 °C | |
| Resistance | 6800 Ω | |
| Resistor Type | FIXED RESISTOR | |
| Surface Mount | NO | |
| Technology | CARBON FILM | |
| Temperature Coefficient | 1200 ppm/°C | |
| Terminal Shape | WIRE | |
| Tolerance | 5% | |
| Working Voltage | 250 V |
CFR25J6K8 Frequently Asked Questions (FAQ)
-
The recommended soldering temperature for CFR25J6K8 is between 230°C to 250°C, with a maximum peak temperature of 260°C.
-
Yes, CFR25J6K8 is compatible with lead-free soldering processes, making it suitable for RoHS-compliant applications.
-
The maximum operating voltage for CFR25J6K8 is 50V, with a maximum surge voltage of 100V.
-
Yes, CFR25J6K8 is designed to operate in high-temperature environments, with a maximum operating temperature of 125°C.
-
Yes, CFR25J6K8 meets the requirements for automotive applications, including AEC-Q200 qualification and compliance with ISO/TS 16949.
