CF14JT1K20 Information
CF14JT1K20 by SEI Stackpole Electronics Inc is a Carbon Film Resistor.
Carbon Film Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for CF14JT1K20
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
31AC8456
|
Newark | Res Cbnflm 1.2K Ohm 5% 1/4W Axl Th Rohs Compliant: Yes |Stackpole Electronics CF14JT1K20 RoHS: Compliant Min Qty: 5000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.0060 | Buy Now |
|
DISTI #
CF14JT1K20CT-ND
|
DigiKey | RES 1.2K OHM 5% 1/4W AXIAL Min Qty: 1 Lead time: 22 Weeks Container: Cut Tape (CT), Tape & Reel (TR) |
50178 In Stock |
|
$0.0051 / $0.1000 | Buy Now |
|
DISTI #
CF14JT1K20
|
Avnet Americas | Res Carbon Film 1.2K Ohm 5% 1/4W -400ppm/?C to 0ppm/?C Conformal AXL Thru-Hole T/R - Tape and Reel (Alt: CF14JT1K20) RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 Lead time: 22 Weeks, 0 Days Container: Reel | 25000 Factory Stock |
|
$0.0063 / $0.0066 | Buy Now |
|
DISTI #
708-CF14JT1K20
|
Mouser Electronics | Carbon Film Resistors - Through Hole 1.2KOhms 1/4W 5% Std Carbon RoHS: Compliant | 8426 |
|
$0.0050 / $0.1000 | Buy Now |
|
DISTI #
V36:1790_07137662
|
Arrow Electronics | Res Carbon Film 1.2K Ohm 5% 0.25W(1/4W) -400ppm/°C to 0ppm/°C AXL T/R RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 Lead time: 22 Weeks Date Code: 2423 | Americas - 5000 |
|
$0.0061 / $0.0070 | Buy Now |
|
DISTI #
V72:2272_07137662
|
Arrow Electronics | Res Carbon Film 1.2K Ohm 5% 0.25W(1/4W) -400ppm/°C to 0ppm/°C AXL T/R RoHS: Compliant Min Qty: 2965 Package Multiple: 1 Lead time: 22 Weeks Date Code: 2219 Container: Cut Strips | Americas - 465 |
|
$0.0071 | Buy Now |
|
|
Future Electronics | CF Series 0.25 W 1.2 KOhm ±5 % 0 to -400 ppm/°C Carbon Film Resistor RoHS: Compliant pbFree: Yes Min Qty: 5000 Package Multiple: 5000 Lead time: 22 Weeks Container: Reel | 5000Reel |
|
$0.0061 / $0.0067 | Buy Now |
|
|
Onlinecomponents.com | Carbon Film Resistor - 1.2 kohm ±5% - 0.25W - Body: 6.00 x 2.30mm Dia - Axial Thru Hole - Tape&Reel RoHS: Compliant | 25000 Factory Stock |
|
$0.0055 / $0.0064 | Buy Now |
|
DISTI #
27170890
|
Verical | Res Carbon Film 1.2K Ohm 5% 0.25W(1/4W) -400ppm/°C to 0ppm/°C AXL T/R RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 | Americas - 40000 |
|
$0.0206 / $0.0256 | Buy Now |
|
DISTI #
87328542
|
Verical | Res Carbon Film 1.2K Ohm 5% 0.25W(1/4W) -400ppm/°C to 0ppm/°C AXL T/R RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 Date Code: 2423 | Americas - 5000 |
|
$0.0061 / $0.0070 | Buy Now |
Part Details for CF14JT1K20
CF14JT1K20 CAD Models
CF14JT1K20 Part Data Attributes
|
|
CF14JT1K20
SEI Stackpole Electronics Inc
Buy Now
Datasheet
|
Compare Parts:
CF14JT1K20
SEI Stackpole Electronics Inc
Fixed Resistor, Carbon Film, 0.25W, 1200ohm, 350V, 5% +/-Tol, -400,0ppm/Cel, Through Hole Mount, AXIAL LEADED
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | STACKPOLE ELECTRONICS INC | |
| Package Description | AXIAL LEADED | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8533.10.00.65 | |
| Factory Lead Time | 22 Weeks | |
| Samacsys Manufacturer | Stackpole Electronics, Inc. | |
| Construction | Tubular | |
| JESD-609 Code | e3 | |
| Lead Diameter | 0.55 mm | |
| Mounting Feature | THROUGH HOLE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 155 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Diameter | 2.3 mm | |
| Package Length | 6 mm | |
| Package Shape | TUBULAR PACKAGE | |
| Package Style | Axial | |
| Packing Method | TR, 13.5 INCH | |
| Rated Power Dissipation (P) | 0.25 W | |
| Rated Temperature | 70 °C | |
| Resistance | 1200 Ω | |
| Resistor Type | FIXED RESISTOR | |
| Surface Mount | NO | |
| Technology | CARBON FILM | |
| Temperature Coefficient | -400,0 ppm/°C | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Shape | WIRE | |
| Tolerance | 5% | |
| Working Voltage | 350 V |
