BSC010N04LS6ATMA1 Information
BSC010N04LS6ATMA1 by Infineon Technologies AG is a Power Field-Effect Transistor.
Power Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for BSC010N04LS6ATMA1
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
02AH1040
|
Newark | Mosfet, N-Ch, 40V, 100A, 175Deg C, 150W, Channel Type:N Channel, Drain Source Voltage Vds:40V, Continuous Drain Current Id:100A, Transistor Mounting:Surface Mount, Rds(On) Test Voltage:10V, Gate Source Threshold Voltage Max:2.3V Rohs Compliant: Yes |Infineon BSC010N04LS6ATMA1 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 3548 |
|
$0.9040 / $1.0700 | Buy Now |
|
DISTI #
86AK4419
|
Newark | Mosfet, N-Ch, 40V, 100A, Tdson Rohs Compliant: Yes |Infineon BSC010N04LS6ATMA1 RoHS: Compliant Min Qty: 5000 Package Multiple: 1 Date Code: 1 Container: Reel | 0 |
|
$0.9450 | Buy Now |
|
DISTI #
BSC010N04LS6ATMA1CT-ND
|
DigiKey | MOSFET N-CH 40V 40A/100A TDSON Min Qty: 1 Lead time: 18 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
9468 In Stock |
|
$0.8252 / $2.2100 | Buy Now |
|
DISTI #
02AH1040
|
Avnet Americas | Power MOSFET, N Channel, 40 V, 100 A, 890 ?ohm, TDSON, Surface Mount - Product that comes on tape, but is not reeled (Alt: 02AH1040) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 18 Weeks, 3 Days Container: Ammo Pack | 3548 Partner Stock |
|
$1.2400 / $2.4000 | Buy Now |
|
DISTI #
BSC010N04LS6ATMA1
|
Avnet Americas | Power MOSFET, N Channel, 40 V, 100 A, 890 ?ohm, TDSON, Surface Mount - Tape and Reel (Alt: BSC010N04LS6ATMA1) RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 Lead time: 18 Weeks, 0 Days Container: Reel | 0 |
|
$0.6730 / $0.7200 | Buy Now |
|
DISTI #
726-BSC010N04LS6ATMA
|
Mouser Electronics | MOSFETs TRENCH <= 40V RoHS: Compliant | 15583 |
|
$0.8420 / $2.1700 | Buy Now |
|
DISTI #
V36:1790_22937529
|
Arrow Electronics | Trans MOSFET N-CH 40V 40A 8-Pin TDSON EP T/R Min Qty: 5000 Package Multiple: 5000 Lead time: 18 Weeks Date Code: 2407 | Americas - 10000 |
|
$0.7010 | Buy Now |
|
|
Future Electronics | 40V 285A 1 mOhm N-ch SuperSO8 5x6 RoHS: Compliant pbFree: Yes Min Qty: 5000 Package Multiple: 5000 Lead time: 18 Weeks Container: Reel | 5000Reel |
|
$0.7950 | Buy Now |
|
DISTI #
77838984
|
Verical | Trans MOSFET N-CH 40V 40A 8-Pin TDSON EP T/R Min Qty: 5000 Package Multiple: 5000 Date Code: 2407 | Americas - 10000 |
|
$0.7075 | Buy Now |
|
DISTI #
62294600
|
Verical | Trans MOSFET N-CH 40V 40A 8-Pin TDSON EP T/R Min Qty: 28 Package Multiple: 1 Date Code: 2224 | Americas - 9743 |
|
$0.8150 / $1.6500 | Buy Now |
Part Details for BSC010N04LS6ATMA1
BSC010N04LS6ATMA1 CAD Models
BSC010N04LS6ATMA1 Part Data Attributes
|
|
BSC010N04LS6ATMA1
Infineon Technologies AG
Buy Now
Datasheet
|
Compare Parts:
BSC010N04LS6ATMA1
Infineon Technologies AG
Power Field-Effect Transistor, 241A I(D), 40V, 0.0014ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TDSON-8
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | INFINEON TECHNOLOGIES AG | |
| Package Description | TDSON-8 | |
| Reach Compliance Code | not_compliant | |
| Factory Lead Time | 18 Weeks, 3 Days | |
| Samacsys Manufacturer | Infineon | |
| Avalanche Energy Rating (Eas) | 376 mJ | |
| Case Connection | DRAIN | |
| Configuration | SINGLE WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 40 V | |
| Drain Current-Max (ID) | 241 A | |
| Drain-source On Resistance-Max | 0.0014 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| Feedback Cap-Max (Crss) | 66 pF | |
| JESD-30 Code | R-PDSO-F8 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 8 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 175 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Polarity/Channel Type | N-CHANNEL | |
| Power Dissipation-Max (Abs) | 150 W | |
| Pulsed Drain Current-Max (IDM) | 1140 A | |
| Reference Standard | IEC-61249-2-21; IEC-68-1 | |
| Surface Mount | YES | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | FLAT | |
| Terminal Position | DUAL | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON |
