BGA8V1BN6E6327XTSA1 Information
BGA8V1BN6E6327XTSA1 by Infineon Technologies AG is an Other Telecom IC.
Other Telecom ICs are under the broader part category of Telecommunication Circuits.
A telecommunications circuit transmits and receives information between points. Key components include transmitters, receivers, amplifiers, and multiplexers. Read more about Telecommunication Circuits on our Telecommunication Circuits part category page.
Price & Stock for BGA8V1BN6E6327XTSA1
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
93AC6969
|
Newark | Rf Amplifier, 3.8Ghz, -40 To 85Deg C, Frequency Min:3.3Ghz, Frequency Max:3.8Ghz, Gain:15Db, Noise Figure Typ:1.2Db, Rf Ic Case Style:Tsnp, No. Of Pins:6Pins, Supply Voltage Min:1.6V, Supply Voltage Max:3.1V, Operating Temperature Rohs Compliant: Yes |Infineon BGA8V1BN6E6327XTSA1 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 0 |
|
$0.3870 / $0.6400 | Buy Now |
|
DISTI #
2156-BGA8V1BN6E6327XTSA1-ND
|
DigiKey | IC RF AMP 3.4GHZ-3.8GHZ TSNP6 Min Qty: 1 Lead time: 8 Weeks Container: Bulk MARKETPLACE PRODUCT |
22500 In Stock |
|
$0.4100 | Buy Now |
|
DISTI #
BGA8V1BN6E6327XTSA1CT-ND
|
DigiKey | IC RF AMP 3.4GHZ-3.8GHZ TSNP6 Min Qty: 1 Lead time: 8 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) | Temporarily Out of Stock |
|
$0.3074 / $0.7200 | Buy Now |
|
DISTI #
BGA8V1BN6E6327XTSA
|
Avnet Americas | Low-Noise Amplifier (LNA), 3.3 GHz to 3.8 GHz, 6 Pins, TSNP - Tape and Reel (Alt: BGA8V1BN6E6327XTSA) RoHS: Compliant Min Qty: 15000 Package Multiple: 15000 Lead time: 8 Weeks, 0 Days Container: Reel | 0 |
|
$0.2791 / $0.2849 | Buy Now |
|
DISTI #
726-BGA8V1BN6E6327XT
|
Mouser Electronics | RF Amplifier RF SILICON MMIC RoHS: Compliant | 6522 |
|
$0.3010 / $1.6000 | Buy Now |
|
DISTI #
85967504
|
Verical | RF Amp Single LNA 3.8GHz 3.1V 6-Pin TSNP T/R RoHS: Compliant Min Qty: 849 Package Multiple: 1 Date Code: 1801 | Americas - 832500 |
|
$0.3045 / $0.4420 | Buy Now |
|
DISTI #
85971509
|
Verical | RF Amp Single LNA 3.8GHz 3.1V 6-Pin TSNP T/R RoHS: Compliant Min Qty: 849 Package Multiple: 1 Date Code: 1701 | Americas - 405000 |
|
$0.3045 / $0.4420 | Buy Now |
|
DISTI #
85967494
|
Verical | RF Amp Single LNA 3.8GHz 3.1V 6-Pin TSNP T/R RoHS: Compliant Min Qty: 849 Package Multiple: 1 Date Code: 1601 | Americas - 285000 |
|
$0.3045 / $0.4420 | Buy Now |
|
DISTI #
85970422
|
Verical | RF Amp Single LNA 3.8GHz 3.1V 6-Pin TSNP T/R RoHS: Compliant Min Qty: 849 Package Multiple: 1 Date Code: 2101 | Americas - 40500 |
|
$0.3045 / $0.4420 | Buy Now |
|
|
Rochester Electronics | LTE / 3G LNAs RoHS: Compliant Status: Active Min Qty: 1 | 1563000 |
|
$0.2436 / $0.3929 | Buy Now |
Part Details for BGA8V1BN6E6327XTSA1
BGA8V1BN6E6327XTSA1 CAD Models
BGA8V1BN6E6327XTSA1 Part Data Attributes
|
|
BGA8V1BN6E6327XTSA1
Infineon Technologies AG
Buy Now
Datasheet
|
Compare Parts:
BGA8V1BN6E6327XTSA1
Infineon Technologies AG
Telecom Circuit,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Not Recommended | |
| Ihs Manufacturer | INFINEON TECHNOLOGIES AG | |
| Package Description | TSNP-6 | |
| Reach Compliance Code | compliant | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 8 Weeks | |
| Samacsys Manufacturer | Infineon | |
| JESD-30 Code | R-PDSO-N6 | |
| Length | 1.1 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | VSON | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, VERY THIN PROFILE | |
| Seated Height-Max | 0.4 mm | |
| Supply Voltage-Nom | 2.8 V | |
| Surface Mount | YES | |
| Telecom IC Type | TELECOM CIRCUIT | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.4 mm | |
| Terminal Position | DUAL | |
| Width | 0.7 mm |
