BGA7H1BN6E6327XTSA1 Information
BGA7H1BN6E6327XTSA1 by Infineon Technologies AG is a Cellular Telephone Circuit.
Cellular Telephone Circuits are under the broader part category of Telecommunication Circuits.
A telecommunications circuit transmits and receives information between points. Key components include transmitters, receivers, amplifiers, and multiplexers. Read more about Telecommunication Circuits on our Telecommunication Circuits part category page.
Price & Stock for BGA7H1BN6E6327XTSA1
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
58AJ1678
|
Newark | Rf Amplifiers, -40 To 85Deg C, Tsnp-6 Rohs Compliant: Yes |Infineon BGA7H1BN6E6327XTSA1 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 1360 |
|
$0.2920 / $0.6100 | Buy Now |
|
DISTI #
448-BGA7H1BN6E6327XTSA1CT-ND
|
DigiKey | IC AMP LTE 1.805-2.69GHZ TSNP6 Min Qty: 1 Lead time: 8 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
14920 In Stock |
|
$0.2544 / $0.6100 | Buy Now |
|
DISTI #
BGA7H1BN6E6327XTSA
|
Avnet Americas | Low-Noise Amplifier (LNA), 1.805 GHz to 2.69 GHz, 6 Pins, TSNP - Tape and Reel (Alt: BGA7H1BN6E6327XTSA) RoHS: Compliant Min Qty: 15000 Package Multiple: 15000 Lead time: 8 Weeks, 0 Days Container: Reel | 0 |
|
$0.2661 | Buy Now |
|
DISTI #
726-BGA7H1BN6E6327XT
|
Mouser Electronics | RF Amplifier RF MMIC SUB 3 GHZ RoHS: Compliant | 5331 |
|
$0.2510 / $0.6100 | Buy Now |
|
DISTI #
85970099
|
Verical | RF Amp Single LNA 2.69GHz 3.6V 6-Pin TSNP T/R RoHS: Compliant Min Qty: 1115 Package Multiple: 1 Date Code: 2101 | Americas - 2850000 |
|
$0.2513 / $0.3364 | Buy Now |
|
DISTI #
85970705
|
Verical | RF Amp Single LNA 2.69GHz 3.6V 6-Pin TSNP T/R RoHS: Compliant Min Qty: 1115 Package Multiple: 1 Date Code: 1901 | Americas - 13330 |
|
$0.2513 / $0.3364 | Buy Now |
|
DISTI #
85970716
|
Verical | RF Amp Single LNA 2.69GHz 3.6V 6-Pin TSNP T/R RoHS: Compliant Min Qty: 1115 Package Multiple: 1 Date Code: 2001 | Americas - 6180 |
|
$0.2513 / $0.3364 | Buy Now |
|
|
Rochester Electronics | Silicon Germanium Low Noise Amplifier for LTE RoHS: Compliant Status: Active Min Qty: 1 | 2869510 |
|
$0.2010 / $0.3242 | Buy Now |
Part Details for BGA7H1BN6E6327XTSA1
BGA7H1BN6E6327XTSA1 CAD Models
BGA7H1BN6E6327XTSA1 Part Data Attributes
|
|
BGA7H1BN6E6327XTSA1
Infineon Technologies AG
Buy Now
Datasheet
|
Compare Parts:
BGA7H1BN6E6327XTSA1
Infineon Technologies AG
RF and Baseband Circuit, PBCC6, TSNP-6
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | INFINEON TECHNOLOGIES AG | |
| Package Description | TSNP-6 | |
| Reach Compliance Code | compliant | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 8 Weeks | |
| Samacsys Manufacturer | Infineon | |
| JESD-30 Code | R-PBCC-N6 | |
| JESD-609 Code | e3 | |
| Length | 1.1 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | VQCCN | |
| Package Shape | RECTANGULAR | |
| Package Style | CHIP CARRIER, VERY THIN PROFILE | |
| Seated Height-Max | 0.4 mm | |
| Supply Voltage-Nom | 2.8 V | |
| Surface Mount | YES | |
| Telecom IC Type | RF AND BASEBAND CIRCUIT | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.4 mm | |
| Terminal Position | BOTTOM | |
| Width | 0.7 mm |
