BD69740FV-GE2 Information
BD69740FV-GE2 by ROHM Semiconductor is a Motion Control Electronic.
Motion Control Electronics are under the broader part category of Signal Circuits.
A signal is an electronic means of transmitting information, either as an analog signal with continuous values or a digital signal with discrete values. Signals are used in various systems and networks. Read more about Signal Circuits on our Signal Circuits part category page.
Price & Stock for BD69740FV-GE2
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
BD69740FV-GE2CT-ND
|
DigiKey | IC MOTOR DRIVER 16SSOPB Min Qty: 1 Lead time: 14 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
2500 In Stock |
|
$0.8602 / $1.7700 | Buy Now |
|
DISTI #
755-BD69740FV-GE2
|
Mouser Electronics | Motor / Motion / Ignition Controllers & Drivers PreDrv PWM Soft SW 4.3-17 SSOP-B16 RoHS: Compliant | 2189 |
|
$0.7980 / $1.7700 | Buy Now |
|
DISTI #
84738900
|
Verical | Motor Driver 12V 16-Pin SSOP-B T/R RoHS: Compliant Min Qty: 58 Package Multiple: 1 | Americas - 100 |
|
$1.2400 / $1.6900 | Buy Now |
|
DISTI #
86986948
|
Verical | Motor Driver 12V 16-Pin SSOP-B T/R RoHS: Compliant Min Qty: 40 Package Multiple: 1 Date Code: 1501 | Americas - 40 |
|
$1.8839 | Buy Now |
|
DISTI #
BD69740FV-GE2
|
Avnet Asia | Multifunction Single-Phase Full-Wave Fan Motor Driver 4.3V to 17V Supply Voltage 36V Output Voltage 10mA Output Current Surface Mount 16-Pin SSOP Emboss T/R (Alt: BD69740FV-GE2) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 24 Weeks, 0 Days | 0 |
|
RFQ |
Part Details for BD69740FV-GE2
BD69740FV-GE2 CAD Models
BD69740FV-GE2 Part Data Attributes
|
|
BD69740FV-GE2
ROHM Semiconductor
Buy Now
Datasheet
|
Compare Parts:
BD69740FV-GE2
ROHM Semiconductor
Brushless DC Motor Controller, PDSO16, 5 X 6.40 MM, 1.35 MM HEIGHT, HALOGEN FREE, SSOP-16
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ROHM CO LTD | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | ROHM Semiconductor | |
| Additional Feature | SEATED HT-CALCULATED | |
| Analog IC - Other Type | BRUSHLESS DC MOTOR CONTROLLER | |
| JESD-30 Code | R-PDSO-G16 | |
| Length | 5 mm | |
| Number of Functions | 1 | |
| Number of Terminals | 16 | |
| Operating Temperature-Max | 105 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | LSSOP | |
| Package Equivalence Code | TSSOP16,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, LOW PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Seated Height-Max | 1.35 mm | |
| Supply Voltage-Max (Vsup) | 17 V | |
| Supply Voltage-Min (Vsup) | 4.3 V | |
| Supply Voltage-Nom (Vsup) | 12 V | |
| Surface Mount | YES | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Width | 4.4 mm |
Alternate Parts for BD69740FV-GE2
This table gives cross-reference parts and alternative options found for BD69740FV-GE2. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of BD69740FV-GE2, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| DRV10974PWPR | Texas Instruments | $0.8859 | 12-V nominal, 2.5-A peak sensorless sinusoidal control 3-phase BLDC motor driver 16-HTSSOP -40 to 125 | BD69740FV-GE2 vs DRV10974PWPR |
| DRV10974RUMR | Texas Instruments | $0.8859 | 12-V nominal, 2.5-A peak sensorless sinusoidal control 3-phase BLDC motor driver 16-WQFN -40 to 125 | BD69740FV-GE2 vs DRV10974RUMR |
| DRV10975ZPWPR | Texas Instruments | $1.0740 | 12-V nominal, 2-A peak sensorless sinusoidal control 3-phase BLDC motor driver 24-HTSSOP -40 to 125 | BD69740FV-GE2 vs DRV10975ZPWPR |
| DRV3220QPHPRQ1 | Texas Instruments | $4.3040 | Automotive 12-V & 24-V battery 3-phase gate driver with enhanced protection 48-HTQFP -40 to 125 | BD69740FV-GE2 vs DRV3220QPHPRQ1 |
| XDRV10974PWPR | Texas Instruments | Check for Price | 12W, 12V 3-Phase Sensorless BLDC Motor Driver 16-HTSSOP -40 to 125 | BD69740FV-GE2 vs XDRV10974PWPR |
| PDRV10975RHFR | Texas Instruments | Check for Price | 25W, 12v 3-phase sensorless BLDC motor driver 24-VQFN -40 to 125 | BD69740FV-GE2 vs PDRV10975RHFR |
