AT42QT1011-TSHR Information
AT42QT1011-TSHR by Microchip Technology Inc is an Other Sensor/Transducer.
Other Sensors/Transducers are under the broader part category of Sensors/Transducers.
Sensors and transducers detect and measure physical quantities like temperature, pressure, and force, converting them into electrical signals for various applications. Read more about Sensors/Transducers on our Sensors/Transducers part category page.
Price & Stock for AT42QT1011-TSHR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
12T1381
|
Newark | Sensor, Touch, Cap, 1Ch, 6Sot-23, Ic Interface Type:1 Wire, Supply Voltage Min:1.8V, Supply Voltage Max:5.5V, Sensor Case Style:Sot-23, No. Of Pins:6Pins, Operating Temperature Min:-40°C, Operating Temperature Max:85°C, Product Rohs Compliant: Yes |Microchip AT42QT1011-TSHR RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 44077 |
|
$0.6700 / $0.7700 | Buy Now |
|
DISTI #
28X3326
|
Newark | Touch Sense, 6-Sot-23, Full Reel, Output Interface:-, Supply Voltage Min:1.8V, Supply Voltage Max:5.5V, Sensor Case/Package:Sot-23, No. Of Pins:6Pins, Operating Temperature Min:-40°C, Operating Temperature Max:85°C, Product Range:-Rohs Compliant: Yes |Microchip AT42QT1011-TSHR RoHS: Compliant Min Qty: 4500 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.6400 | Buy Now |
|
DISTI #
AT42QT1011-TSHRCT-ND
|
DigiKey | IC TOUCH SENSOR 1KEY SOT23-6 Min Qty: 1 Lead time: 7 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
8573 In Stock |
|
$0.6300 / $0.7700 | Buy Now |
|
DISTI #
AT42QT1011-TSHR
|
Avnet Americas | Capacitive Touch Sensor, One-Channel, 1.8 V, 5.5 V, SOT-23 - Tape and Reel (Alt: AT42QT1011-TSHR) RoHS: Compliant Min Qty: 4500 Package Multiple: 4500 Lead time: 7 Weeks, 0 Days Container: Reel | 0 |
|
$0.6435 / $0.6875 | Buy Now |
|
DISTI #
556-AT42QT1011-TSHR
|
Mouser Electronics | Capacitive Touch Sensors One-Channel Touch Sensor IC RoHS: Compliant | 0 |
|
$0.6300 / $0.7700 | Order Now |
|
DISTI #
V72:2272_07157230
|
Arrow Electronics | Capacitive Touch Screen 1 Key 6-Pin SOT-23 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 7 Weeks Date Code: 2337 Container: Cut Strips | Americas - 8890 |
|
$0.4255 / $0.7074 | Buy Now |
|
DISTI #
AT42QT1011-TSHR
|
Microchip Technology Inc | One-Channel Touch Sensor IC, SOT-23, Projected EOL: 2039-11-08 COO: Thailand ECCN: EAR99 RoHS: Compliant Lead time: 7 Weeks, 0 Days Container: Reel |
0 Alternates Available |
|
$0.5600 / $0.7700 | Buy Now |
|
|
Onlinecomponents.com | Capacitive Touch Sensor - One-Channel - 1.8 V - 5.5 V - SOIC-23 - 6 Pins RoHS: Compliant |
10750 In Stock |
|
$0.5990 / $0.6180 | Buy Now |
|
DISTI #
66427974
|
Verical | Capacitive Touch Screen 1 Key 6-Pin SOT-23 T/R RoHS: Compliant Min Qty: 500 Package Multiple: 500 Date Code: 2304 | Americas - 10500 |
|
$0.7865 / $0.8034 | Buy Now |
|
DISTI #
73505085
|
Verical | Capacitive Touch Screen 1 Key 6-Pin SOT-23 T/R RoHS: Compliant Min Qty: 9 Package Multiple: 1 Date Code: 2337 | Americas - 8890 |
|
$0.4255 / $0.4431 | Buy Now |
Part Details for AT42QT1011-TSHR
AT42QT1011-TSHR CAD Models
AT42QT1011-TSHR Part Data Attributes
|
|
AT42QT1011-TSHR
Microchip Technology Inc
Buy Now
Datasheet
|
Compare Parts:
AT42QT1011-TSHR
Microchip Technology Inc
IC TOUCH SENSOR 1KEY SOT23-6
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | MICROCHIP TECHNOLOGY INC | |
| Package Description | SOT-23, 6 PIN | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.31.00.01 | |
| Factory Lead Time | 7 Weeks | |
| Date Of Intro | 2016-12-19 | |
| Samacsys Manufacturer | Microchip | |
| Body Breadth | 1.6 mm | |
| Body Height | 1.1 mm | |
| Body Length or Diameter | 2.9 mm | |
| JESD-609 Code | e3 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output | DIGITAL | |
| Output Range | 0.50-2.30V | |
| Output Type | DIGITAL VOLTAGE | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape/Style | RECTANGULAR | |
| Screening Level | TS 16949 | |
| Sensors/Transducers Type | CAPACITIVE TOUCH SENSOR | |
| Supply Voltage-Max | 5.5 V | |
| Supply Voltage-Min | 1.8 V | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) |
Alternate Parts for AT42QT1011-TSHR
This table gives cross-reference parts and alternative options found for AT42QT1011-TSHR. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of AT42QT1011-TSHR, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| AT42QT1010-TSHR | Microchip Technology Inc | $0.6223 | IC TOUCH SENSOR 1KEY SOT23-6 | AT42QT1011-TSHR vs AT42QT1010-TSHR |
| AT42QT1012-TSHR | Microchip Technology Inc | $0.7155 | IC TOUCH SENSOR 1KEY SOT23-6 | AT42QT1011-TSHR vs AT42QT1012-TSHR |
