Part Details for ASFL1-20.000MHZ-EK-T
ASFL1-20.000MHZ-EK-T CAD Models
ASFL1-20.000MHZ-EK-T Part Data Attributes
|
|
ASFL1-20.000MHZ-EK-T
Abracon Corporation
Buy Now
Datasheet
|
Compare Parts:
ASFL1-20.000MHZ-EK-T
Abracon Corporation
XTAL OSC XO 20.0000MHZ HCMOS TTL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ABRACON LLC | |
| Package Description | ROHS COMPLIANT, SMD, 4 PIN | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 14 Weeks | |
| Samacsys Manufacturer | ABRACON | |
| Additional Feature | TRI-STATE; ENABLE/DISABLE FUNCTION; TAPE AND REEL | |
| Fall Time-Max | 10 ns | |
| Frequency Adjustment-Mechanical | NO | |
| Frequency Stability | 30% | |
| JESD-609 Code | e4 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 4 | |
| Operating Frequency-Nom | 20 MHz | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | -20 °C | |
| Oscillator Type | HCMOS/TTL | |
| Output Load | 5 TTL, 15 pF | |
| Physical Dimension | 5.0mm x 3.2mm x 1.3mm | |
| Rise Time-Max | 10 ns | |
| Supply Voltage-Max | 3.63 V | |
| Supply Voltage-Min | 2.97 V | |
| Supply Voltage-Nom | 3.3 V | |
| Surface Mount | YES | |
| Symmetry-Max | 40/60 % | |
| Terminal Finish | Gold (Au) - with Nickel (Ni) barrier |
