ACHL-40.000MHZ-EK by: Abracon Corporation

XTAL OSC XO 40.0000MHZ HCMOS TTL

Part Details for ACHL-40.000MHZ-EK by Abracon Corporation

Results Overview of ACHL-40.000MHZ-EK by Abracon Corporation

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Security and Surveillance Environmental Monitoring Internet of Things (IoT) Space Technology Smart Cities Aerospace and Defense Healthcare Agriculture Technology Virtual Reality (VR), Augmented Reality (AR), and Vision Systems Medical Imaging Robotics and Drones

ACHL-40.000MHZ-EK Information

ACHL-40.000MHZ-EK by Abracon Corporation is an Other Oscillator.
Other Oscillators are under the broader part category of Oscillators.

Oscillators are electronic components that produce sine or square waves in order to convert signals. Read more about Oscillators on our Oscillators part category page.

Price & Stock for ACHL-40.000MHZ-EK

Part # Distributor Description Stock Price Buy
DISTI # 13J1862
Newark Oscillator, 40Mhz, Dip-4, Hcmos/Ttl, Frequency Nom:40Mhz, Frequency Stability +/-:30Ppm, Oscillator Case:Through Hole, 13.2Mm X 13.2Mm, Supply Voltage Nom:3.3V, Product Range:Achl Series, Operating Temperature Min:-20°C Rohs Compliant: Yes |Abracon ACHL-40.000MHZ-EK RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk 8
  • 1 $3.4300
  • 10 $3.0600
  • 25 $2.8500
  • 50 $2.6400
  • 100 $2.3700
  • 500 $2.1800
  • 1,000 $1.9500
  • 2,500 $1.8300
$1.8300 / $3.4300 Buy Now
DISTI # 535-9198-5-ND
DigiKey XTAL OSC XO 40.0000MHZ HCMOS TTL Min Qty: 1 Lead time: 20 Weeks Container: Tube 575
In Stock
  • 1 $4.3800
  • 40 $3.3428
  • 80 $3.0789
  • 2,520 $3.0548
$3.0548 / $4.3800 Buy Now
DISTI # 13J1862
Avnet Americas Oscillator, 40 MHz, 30 ppm, Through Hole, 13.2mm x 13.2mm, 3.3 V, HCMOS / TTL, ACHL - Bulk (Alt: 13J1862) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 38 Weeks, 1 Days Container: Bulk 8 Partner Stock
  • 1 $2.0300
$2.0300 Buy Now
DISTI # ACHL-40.000MHZ-EK
Avnet Americas Oscillator, 40 MHz, 30 ppm, Through Hole, 13.2mm x 13.2mm, 3.3 V, HCMOS / TTL, ACHL - Rail/Tube (Alt: ACHL-40.000MHZ-EK) RoHS: Compliant Min Qty: 1000 Package Multiple: 40 Lead time: 20 Weeks, 0 Days Container: Tube 0
  • 1,000 $2.9229
  • 1,080 $2.8749
  • 2,080 $2.8272
  • 5,000 $2.6401
  • 10,000 $2.5945
$2.5945 / $2.9229 Buy Now
DISTI # 815-ACHL-40-EK
Mouser Electronics Standard Clock Oscillators Crystal Oscillator 8-DIP, 4 Leads (Half Size, Metal Can) 40MHz +/-30ppm -20C - 70C CMOS 3.3V RoHS: Compliant 752
  • 1 $3.2800
  • 10 $3.2400
  • 40 $3.1100
  • 2,520 $2.8500
$2.8500 / $3.2800 Buy Now
Onlinecomponents.com Oscillator XO 40MHz ±30ppm 15pF HCMOS/TTL 60% 3.3V 4-Pin DIP Module Thru-Hole RoHS: Compliant 1000 In Stock
  • 40 $2.9700
  • 80 $2.9600
  • 280 $2.9300
  • 520 $2.9100
  • 1,000 $2.9000
  • 2,520 $2.7800
  • 5,000 $2.7700
  • 7,520 $2.7500
$2.7500 / $2.9700 Buy Now
DISTI # 82392242
Verical Oscillator XO 40MHz ±30ppm 15pF HCMOS/TTL 60% 3.3V 4-Pin DIP Module Thru-Hole RoHS: Compliant Min Qty: 40 Package Multiple: 40 Date Code: 2417 Americas - 1000
  • 40 $3.4941
  • 80 $3.4824
  • 280 $3.4471
  • 520 $3.4235
  • 1,000 $3.4118
$3.4118 / $3.4941 Buy Now
DISTI # ACHL-40.000MHZ-EK
Avnet Abacus Oscillator 40 MHz 30 ppm Through Hole 132mm x 132mm 33 V HCMOS TTL ACHL (Alt: ACHL-40.000MHZ-EK) RoHS: Compliant Min Qty: 1000 Package Multiple: 40 Lead time: 22 Weeks, 0 Days Abacus - 0
Buy Now
Master Electronics Oscillator XO 40MHz ±30ppm 15pF HCMOS/TTL 60% 3.3V 4-Pin DIP Module Thru-Hole RoHS: Compliant 1000 In Stock
  • 40 $2.9700
  • 80 $2.9600
  • 280 $2.9300
  • 520 $2.9100
  • 1,000 $2.9000
  • 2,520 $2.7800
  • 5,000 $2.7700
  • 7,520 $2.7500
$2.7500 / $2.9700 Buy Now

Part Details for ACHL-40.000MHZ-EK

ACHL-40.000MHZ-EK CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

ACHL-40.000MHZ-EK Part Data Attributes

Parametric Data
ACHL-40.000MHZ-EK Abracon Corporation
Buy Now Datasheet
Compare Parts:
ACHL-40.000MHZ-EK Abracon Corporation XTAL OSC XO 40.0000MHZ HCMOS TTL
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer ABRACON LLC
Package Description DIP-8/4
Reach Compliance Code compliant
Factory Lead Time 20 Weeks
Samacsys Manufacturer ABRACON
Fall Time-Max 5 ns
Frequency Adjustment-Mechanical NO
Frequency Stability 30%
Mounting Feature THROUGH HOLE MOUNT
Number of Terminals 8
Operating Frequency-Nom 40 MHz
Operating Temperature-Max 70 °C
Operating Temperature-Min -20 °C
Oscillator Type HCMOS/TTL
Output Load 5 TTL, 15 pF
Package Equivalence Code DIP4/8,.3
Physical Dimension 13.2mm x 13.2mm x 6.3mm
Rise Time-Max 5 ns
Supply Current-Max 5 mA
Supply Voltage-Max 3.63 V
Supply Voltage-Min 2.97 V
Supply Voltage-Nom 3.3 V
Surface Mount NO
Symmetry-Max 40/60 %
