AC01000006807JA100 Information
AC01000006807JA100 by Vishay Intertechnologies is a Wire Wound Resistor.
Wire Wound Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for AC01000006807JA100
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
24R5479
|
Newark | Through Hole Wirewound Resistor, Ac Series, 0.68 Ohm, 1 W, - 5%, Axial Leaded Rohs Compliant: Yes |Vishay AC01000006807JA100 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk | 483 |
|
$0.0440 | Buy Now |
|
DISTI #
24R5479
|
Avnet Americas | AC01 R68 5% A1 - Bulk (Alt: 24R5479) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 18 Weeks, 4 Days Container: Bulk | 483 Partner Stock |
|
$0.4130 / $0.7500 | Buy Now |
|
DISTI #
AC01000006807JA100
|
Avnet Americas | AC01 R68 5% A1 - Ammo Pack (Alt: AC01000006807JA100) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 8 Weeks, 0 Days Container: Ammo Pack | 0 |
|
$0.2044 / $0.2213 | Buy Now |
|
DISTI #
594-AC01000006807JA1
|
Mouser Electronics | Wirewound Resistors - Through Hole AC01 R68 5% A1 RoHS: Compliant | 785 |
|
$0.2380 / $1.1800 | Buy Now |
|
DISTI #
AC01000006807JA100
|
Avnet Abacus | AC01 R68 5 A1 (Alt: AC01000006807JA100) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 11 Weeks, 0 Days | Abacus - 0 |
|
Buy Now |
Part Details for AC01000006807JA100
AC01000006807JA100 CAD Models
AC01000006807JA100 Part Data Attributes
|
|
AC01000006807JA100
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
AC01000006807JA100
Vishay Intertechnologies
Fixed Resistor, Wire Wound, 1W, 0.68ohm, 5% +/-Tol, 80ppm/Cel, Through Hole Mount, AXIAL LEADED
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | AXIAL LEADED | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8533.21.00.80 | |
| Factory Lead Time | 18 Weeks, 4 Days | |
| Samacsys Manufacturer | Vishay | |
| Additional Feature | FLAME PROOF | |
| Construction | Tubular | |
| JESD-609 Code | e3 | |
| Lead Diameter | 0.8 mm | |
| Mounting Feature | THROUGH HOLE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 250 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Diameter | 4.3 mm | |
| Package Length | 11 mm | |
| Package Style | Axial | |
| Packing Method | AMMO PACK | |
| Rated Power Dissipation (P) | 1 W | |
| Rated Temperature | 40 °C | |
| Resistance | 0.68 Ω | |
| Resistor Type | FIXED RESISTOR | |
| Surface Mount | NO | |
| Technology | WIRE WOUND | |
| Temperature Coefficient | -10,-80 ppm/°C | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Shape | WIRE | |
| Tolerance | 5% | |
| Working Voltage | 0.8247 V |
