87759-2014 by: Molex

Board Connector, 20 Contact(s), 2 Row(s), Male, Straight, 0.079 inch Pitch, Surface Mount Terminal, Locking, Black Insulator, Receptacle,

Part Details for 87759-2014 by Molex

Results Overview of 87759-2014 by Molex

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Industrial Automation

87759-2014 Information

87759-2014 by Molex is a Header and Edge Type Connector.
Headers and Edge Type Connectors are under the broader part category of Connectors.

Connectors are devices that join electrical termination points to form circuits. With various types designed for specific functions like data, power, or signal transmission, choosing the right connector is essential for compatibility and device performance. Read more about Connectors on our Connectors part category page.

Available Datasheets

Part # Manufacturer Description Datasheet
5962-8775901M2A Texas Instruments Octal Buffers/Drivers With 3-State Outputs 20-LCCC -55 to 125
5962-8775901MSA Texas Instruments Octal Buffers/Drivers With 3-State Outputs 20-CFP -55 to 125
5962-8775901MRA Texas Instruments Octal Buffers/Drivers With 3-State Outputs 20-CDIP -55 to 125

Price & Stock for 87759-2014

Part # Distributor Description Stock Price Buy
DISTI # 85AJ8603
Newark Conn, Hdr, 20Pos, 2Row, 2Mm, Smt Rohs Compliant: Yes |Molex 87759-2014 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk 1117
  • 1 $2.7200
  • 10 $2.6400
  • 25 $2.5600
  • 50 $2.5000
  • 100 $2.4300
  • 250 $2.3700
  • 500 $2.3300
  • 1,000 $2.3000
$2.3000 / $2.7200 Buy Now
DISTI # 0877592014
Avnet Americas Conn Board to Board HDR 20 POS 2mm Solder ST SMD Tube - Rail/Tube (Alt: 0877592014) RoHS: Compliant Min Qty: 1170 Package Multiple: 1170 Lead time: 34 Weeks, 0 Days Container: Tube 0
  • 1,170 $1.3204
  • 2,340 $1.2975
  • 4,680 $1.1603
  • 7,020 $1.1483
  • 9,360 $1.1424
$1.1424 / $1.3204 Buy Now
DISTI # 538-87759-2014
Mouser Electronics Headers & Wire Housings MGrid Hdr SMT D/R W/ W/OCap .38AuLF 20Ckt RoHS: Compliant 912
  • 1 $2.6500
  • 10 $2.4100
  • 26 $2.2600
  • 104 $2.1300
  • 260 $1.8600
  • 520 $1.8100
  • 1,014 $1.5400
  • 2,522 $1.4300
  • 5,018 $1.3800
$1.3800 / $2.6500 Buy Now
Onlinecomponents.com 2.00mm Pitch Milli-Grid™ Header, Surface Mount, Vertical, 20 Circuits, 0.38µm Gold (Au) Selective Plating, without Press-fit Plastic Pegs, Lead-Free RoHS: Compliant 0
  • 293 $1.7900
  • 585 $1.5100
  • 1,170 $1.3100
  • 2,500 $1.2700
$1.2700 / $1.7900 Buy Now
Vyrian Connectors 662
RFQ

Part Details for 87759-2014

87759-2014 CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

87759-2014 Part Data Attributes

Parametric Data
87759-2014 Molex
Buy Now Datasheet
Compare Parts:
87759-2014 Molex Board Connector, 20 Contact(s), 2 Row(s), Male, Straight, 0.079 inch Pitch, Surface Mount Terminal, Locking, Black Insulator, Receptacle,
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer MOLEX LLC
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8536.69.40.40
Factory Lead Time 34 Weeks
Samacsys Manufacturer Molex
Additional Feature TUBE PACKAGE & ROHS COMPLIANT
Body Breadth 0.551 inch
Body Depth 0.106 inch
Body Length 0.784 inch
Body/Shell Style RECEPTACLE
Connector Type BOARD CONNECTOR
Contact Finish Mating NOT SPECIFIED
Contact Finish Termination MATTE TIN OVER NICKEL
Contact Gender MALE
Contact Material PHOSPHOR BRONZE
Contact Pattern RECTANGULAR
Contact Style SQ PIN-SKT
DIN Conformance NO
Dielectric Withstanding Voltage 500VAC V
Filter Feature NO
IEC Conformance NO
Insulation Resistance 1000000000 Ω
Insulator Color BLACK
Insulator Material GLASS FILLED POLYAMIDE
MIL Conformance NO
Mating Contact Pitch 0.079 inch
Mating Contact Row Spacing 0.079 inch
Mixed Contacts NO
Mounting Option 1 LOCKING
Mounting Style STRAIGHT
Mounting Type BOARD
Number Of Connectors ONE
Number Of PCB Rows 2
Number of Rows Loaded 2
Operating Temperature-Max 125 °C
Operating Temperature-Min -55 °C
Option GENERAL PURPOSE
PCB Contact Pattern RECTANGULAR
Plating Thickness 15u inch
Rated Current (Signal) 2 A
Reference Standard UL
Terminal Pitch 2 mm
Termination Type SURFACE MOUNT
Total Number of Contacts 20
UL Flammability Code 94V-0
