821054PQFG Information
821054PQFG by Renesas Electronics Corporation is a Codec.
Codecs are under the broader part category of Telecommunication Circuits.
A telecommunications circuit transmits and receives information between points. Key components include transmitters, receivers, amplifiers, and multiplexers. Read more about Telecommunication Circuits on our Telecommunication Circuits part category page.
Price & Stock for 821054PQFG
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
42AH2780
|
Newark | Programmable Pcm Codec, -40 To 85Deg C Rohs Compliant: Yes |Renesas 821054PQFG RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 0 |
|
$8.0200 / $12.2000 | Buy Now |
|
DISTI #
800-2516-5-ND
|
DigiKey | IC PCM CODEC QUAD MPI 64QFP Min Qty: 1 Lead time: 18 Weeks Container: Tube | Limited Supply - Call |
|
$8.4394 / $12.8200 | Buy Now |
|
DISTI #
821054PQFG
|
Avnet Americas | 4 Channel PCM CODEC, MPI Interface, 5.0V - Trays (Alt: 821054PQFG) RoHS: Compliant Min Qty: 504 Package Multiple: 84 Lead time: 18 Weeks, 0 Days Container: Tray | 0 |
|
$7.5600 | Buy Now |
|
DISTI #
972-821054PQFG
|
Mouser Electronics | Interface - CODECs QUAD PCM CODEC RoHS: Compliant | 0 |
|
Order Now | |
|
DISTI #
821054PQFG
|
Avnet Silica | 4 Channel PCM CODEC MPI Interface 50V (Alt: 821054PQFG) RoHS: Compliant Min Qty: 504 Package Multiple: 84 Lead time: 19 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
|
Cytech Systems Limited | IC PCM CODEC QUAD MPI 64QFP | 168 |
|
RFQ |
Part Details for 821054PQFG
821054PQFG CAD Models
821054PQFG Part Data Attributes
|
|
821054PQFG
Renesas Electronics Corporation
Buy Now
Datasheet
|
Compare Parts:
821054PQFG
Renesas Electronics Corporation
4 Channel PCM CODEC, MPI Interface, 5.0V, PQFP84/Tray
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | End Of Life | |
| Ihs Manufacturer | RENESAS ELECTRONICS CORP | |
| Part Package Code | PQFP | |
| Pin Count | 64 | |
| Manufacturer Package Code | PMG64 | |
| Reach Compliance Code | compliant | |
| ECCN Code | NLR | |
| HTS Code | 8542390001 | |
| Factory Lead Time | 18 Weeks | |
| Samacsys Manufacturer | Renesas Electronics | |
| Companding Law | A/MU-LAW | |
| Filter | YES | |
| JESD-30 Code | S-PQFP-G64 | |
| JESD-609 Code | e3 | |
| Length | 14 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 1 | |
| Number of Terminals | 64 | |
| Operating Mode | SYNCHRONOUS | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | QFP | |
| Package Shape | SQUARE | |
| Package Style | FLATPACK | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 2.45 mm | |
| Supply Voltage-Nom | 5 V | |
| Surface Mount | YES | |
| Telecom IC Type | PCM CODEC | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | MATTE TIN | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.8 mm | |
| Terminal Position | QUAD | |
| Width | 14 mm |
Alternate Parts for 821054PQFG
This table gives cross-reference parts and alternative options found for 821054PQFG. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of 821054PQFG, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| 821054PQF | Integrated Device Technology Inc | Check for Price | PCM Codec, A/MU-Law, 1-Func, PQFP64, PLASTIC, QFP-64 | 821054PQFG vs 821054PQF |
