74HC4066D Information
74HC4066D by Toshiba America Electronic Components is a Multiplexer or Switch.
Multiplexers or Switches are under the broader part category of Signal Circuits.
A signal is an electronic means of transmitting information, either as an analog signal with continuous values or a digital signal with discrete values. Signals are used in various systems and networks. Read more about Signal Circuits on our Signal Circuits part category page.
Price & Stock for 74HC4066D
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
264-74HC4066DCT-ND
|
DigiKey | IC MUX QUAD 1:1 80OHM 14SOIC Min Qty: 1 Lead time: 20 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
12053 In Stock |
|
$0.1546 / $0.4100 | Buy Now |
|
DISTI #
74HC4066D
|
Avnet Americas | Analog Switch Quad SPST 14-Pin SOIC Emboss T/R - Tape and Reel (Alt: 74HC4066D) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 20 Weeks, 0 Days Container: Reel | 0 |
|
$0.1343 / $0.1440 | Buy Now |
|
DISTI #
757-74HC4066D
|
Mouser Electronics | Encoders, Decoders, Multiplexers & Demultiplexers CMOS Logic IC 500mW 2.0-6.0V RoHS: Compliant | 7045 |
|
$0.1570 / $0.4000 | Buy Now |
Part Details for 74HC4066D
74HC4066D CAD Models
74HC4066D Part Data Attributes
|
|
74HC4066D
Toshiba America Electronic Components
Buy Now
Datasheet
|
Compare Parts:
74HC4066D
Toshiba America Electronic Components
SPST
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TOSHIBA CORP | |
| Reach Compliance Code | compliant | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 20 Weeks | |
| Samacsys Manufacturer | Toshiba | |
| Analog IC - Other Type | SPST | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
74HC4066D Frequently Asked Questions (FAQ)
-
The maximum frequency of operation for the 74HC4066D is typically around 10 MHz, but it can vary depending on the specific application and operating conditions.
-
To ensure signal integrity, use proper PCB layout techniques, such as keeping signal traces short and away from noise sources, using ground planes, and adding decoupling capacitors near the device.
-
The recommended power-on sequence is to apply VCC first, followed by the input signals. This helps prevent unwanted switching during power-up.
-
Yes, the 74HC4066D is compatible with 5V systems, but ensure that the input signals do not exceed the maximum rating of 7V.
-
Ensure good airflow around the device, use a heat sink if necessary, and avoid operating the device near its maximum temperature rating of 125°C.
