5-146274-2 Information
5-146274-2 by TE Connectivity is a Header and Edge Type Connector.
Headers and Edge Type Connectors are under the broader part category of Connectors.
Connectors are devices that join electrical termination points to form circuits. With various types designed for specific functions like data, power, or signal transmission, choosing the right connector is essential for compatibility and device performance. Read more about Connectors on our Connectors part category page.
Price & Stock for 5-146274-2
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
93K7870
|
Newark | Board-Board Connector, Header, 1 Position, 1Row, Connector Systems:Board-To-Board, Pitch Spacing:2.54Mm, No. Of Rows:1Rows, No. Of Contacts:2Contacts, Contact Termination Type:Through Hole Straight, Connector Shroud:Unshrouded Rohs Compliant: Yes |Amp Te Connectivity 5-146274-2 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk | 1398 |
|
$0.1460 / $0.2700 | Buy Now |
|
DISTI #
75AJ0601
|
Newark | Conn, Header, 2Pos, 1Row, 2.54Mm Rohs Compliant: Yes |Amp Te Connectivity 5-146274-2 RoHS: Compliant Min Qty: 10 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
$0.1740 / $0.3040 | Buy Now |
|
DISTI #
A105200-ND
|
DigiKey | CONN HEADER VERT 2POS 2.54MM Min Qty: 1 Lead time: 18 Weeks Container: Bulk |
6266 In Stock |
|
$0.1552 / $0.3000 | Buy Now |
|
DISTI #
5-146274-2
|
Avnet Americas | Conn Unshrouded Header 2 POS 2.54mm Solder ST Through Hole - Bulk (Alt: 5-146274-2) RoHS: Compliant Min Qty: 500 Package Multiple: 1 Lead time: 18 Weeks, 0 Days Container: Bulk | 139519495 Factory Stock |
|
$0.1109 / $0.1154 | Buy Now |
|
DISTI #
571-5-146274-2
|
Mouser Electronics | Headers & Wire Housings 2P HEADER TIN single row RoHS: Compliant | 8999 |
|
$0.1330 / $0.3000 | Buy Now |
|
DISTI #
V36:1790_11868594
|
Arrow Electronics | Conn Unshrouded Header HDR 2 POS 2.54mm Solder ST Top Entry Thru-Hole Carton RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 18 Weeks Date Code: 2228 | Americas - 8954 |
|
$0.1003 / $0.1225 | Buy Now |
|
DISTI #
70085234
|
RS | PCB Breakaway Header, .100, 2-Pos, 8.08 mm, 1 Row, AMPMODU Headers Series Min Qty: 20000 Package Multiple: 1 Container: Bulk | 0 |
|
$0.2710 / $0.3390 | RFQ |
|
|
Future Electronics | AMPMODU 2 Position 8.08 mm Post Length Single Row .100 Inch Breakaway Header RoHS: Compliant pbFree: Yes Min Qty: 500 Package Multiple: 500 Lead time: 18 Weeks Container: Box | 33000Box |
|
$0.1120 / $0.1200 | Buy Now |
|
DISTI #
AMP5-146274-2
|
Heilind Electronics | 02 MODII HDR SRST B/A .100CL | Americas - 9130 in Stock |
|
$0.0999 / $0.1263 | Buy Now |
|
|
Onlinecomponents.com | 02 MODII HDR SRST B/A .100CL RoHS: Compliant |
42798 In Stock |
|
$0.0965 / $0.1156 | Buy Now |
Part Details for 5-146274-2
5-146274-2 CAD Models
5-146274-2 Part Data Attributes
|
|
5-146274-2
TE Connectivity
Buy Now
Datasheet
|
Compare Parts:
5-146274-2
TE Connectivity
02 MODII HDR SRST B/A .100CL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TE CONNECTIVITY LTD | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 18 Weeks | |
| Samacsys Manufacturer | TE Connectivity | |
| Connector Type | BOARD CONNECTOR | |
| Contact Finish Mating | NOT APPLICABLE | |
| Contact Finish Termination | Tin (Sn) - with Nickel (Ni) barrier | |
| Contact Gender | MALE | |
| Contact Material | NOT APPLICABLE | |
| DIN Conformance | NO | |
| EMI Shielded | NO | |
| Empty Shell | NO | |
| Filter Feature | NO | |
| IEC Conformance | NO | |
| Insulator Color | BLACK | |
| Insulator Material | GLASS FILLED LIQUID CRYSTAL POLYMER | |
| JESD-609 Code | e3 | |
| MIL Conformance | NO | |
| Mains Connector Rating | 3A | |
| Mixed Contacts | NO | |
| Mounting Style | STRAIGHT | |
| Mounting Type | BOARD | |
| Number Of Connectors | ONE | |
| Number of Ports | 1 | |
| Number of Rows Loaded | 1 | |
| Operating Temperature-Max | 105 °C | |
| Operating Temperature-Min | -65 °C | |
| Option | GENERAL PURPOSE | |
| Panel Mount | NO | |
| Plating Thickness | 200u inch | |
| Rated Current (Signal) | 3 A | |
| Reference Standard | CSA, LR, U | |
| Terminal Length | 0.125 inch | |
| Terminal Pitch | 2.54 mm | |
| Termination Type | SOLDER | |
| Total Number of Contacts | 2 | |
| UL Flammability Code | 94V-0 |
