3426-0000T Information
3426-0000T by 3M Interconnect is a Header and Edge Type Connector.
Headers and Edge Type Connectors are under the broader part category of Connectors.
Connectors are devices that join electrical termination points to form circuits. With various types designed for specific functions like data, power, or signal transmission, choosing the right connector is essential for compatibility and device performance. Read more about Connectors on our Connectors part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| 10034264-101LF | Amphenol Communications Solutions | AirMax VS®, Backplane Connectors, Header, Right Angle, Press-Fit, 3 Pair, 10 Column, 90 Position, 2.00mm (0.079in) Pitch | |
| 68023-426HLF | Amphenol Communications Solutions | BergStik® 2.54mm, Board To Board Connector, Unshrouded Header, Through Hole, Single Row, 26 Positions, 2.54mm Pitch, RightAngle, 3.42mm (0.135in) Mating, 7.75mm (0.305in) Tail. | |
| 69133-426HLF | Amphenol Communications Solutions | BergStik®, Board to Board connector, Unshrouded Vertical Header, Through Hole, Double Row, 26 Positions, 2.54 mm (0.100in) Pitch. |
Part Details for 3426-0000T
3426-0000T CAD Models
3426-0000T Part Data Attributes
|
|
3426-0000T
3M Interconnect
Buy Now
Datasheet
|
Compare Parts:
3426-0000T
3M Interconnect
Board Connector, 50 Contact(s), 1 Row(s), Male, Straight, 0.2 inch Pitch, Solder Terminal, Gray Insulator,
|
| Pbfree Code | No | |
| Rohs Code | No | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | 3M ELECTRONIC PRODUCTS DIVISION | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | 3M | |
| Additional Feature | LOW PROFILE | |
| Body Breadth | 0.402 inch | |
| Body Depth | 0.22 inch | |
| Body Length | 2.701 inch | |
| Connector Type | BOARD CONNECTOR | |
| Contact Finish Mating | TIN LEAD (200) OVER NICKEL (100) | |
| Contact Finish Termination | Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier | |
| Contact Gender | MALE | |
| Contact Material | COPPER ALLOY | |
| Contact Pattern | STAGGERED | |
| Contact Style | IDC | |
| DIN Conformance | NO | |
| Dielectric Withstanding Voltage | 1000VAC V | |
| Filter Feature | NO | |
| IEC Conformance | NO | |
| Insulation Resistance | 1000000000 Ω | |
| Insulator Color | GRAY | |
| Insulator Material | GLASS FILLED POLYESTER | |
| JESD-609 Code | e0 | |
| MIL Conformance | NO | |
| Mating Contact Pitch | 0.2 inch | |
| Mating Contact Row Spacing | 0.1 inch | |
| Mixed Contacts | NO | |
| Mounting Style | STRAIGHT | |
| Mounting Type | BOARD | |
| Number Of Connectors | ONE | |
| Number Of PCB Rows | 4 | |
| Number of Rows Loaded | 1 | |
| Operating Temperature-Max | 120 °C | |
| Operating Temperature-Min | -55 °C | |
| PCB Contact Pattern | STAGGERED | |
| PCB Contact Row Spacing | 2.54 mm | |
| Plating Thickness | 200u inch | |
| Rated Current (Signal) | 1 A | |
| Reference Standard | UL | |
| Terminal Length | 0.097 inch | |
| Terminal Pitch | 5.08 mm | |
| Termination Type | SOLDER | |
| Total Number of Contacts | 50 | |
| UL Flammability Code | 94V-0 |
