2N7002DW-TP Information
2N7002DW-TP by Micro Commercial Components is a Small Signal Field-Effect Transistor.
Small Signal Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for 2N7002DW-TP
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
22AM0718
|
Newark | Mosfet, N-Channel, 60V, 0.115A, Sot-363 Rohs Compliant: Yes |Micro Commercial Components 2N7002DW-TP RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 2600 |
|
$0.1100 / $0.3640 | Buy Now |
|
DISTI #
2N7002DW-TPCT-ND
|
DigiKey | MOSFET 2N-CH 60V 0.115A SOT363 Min Qty: 1 Lead time: 18 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
1065407 In Stock |
|
$0.0437 / $0.3400 | Buy Now |
|
DISTI #
833-2N7002DW-TP
|
Mouser Electronics | MOSFETs Dual N-CH 60V 115mA RoHS: Compliant | 12744 |
|
$0.0580 / $0.3400 | Buy Now |
|
DISTI #
E54:1762_08671004
|
Arrow Electronics | Trans MOSFET N-CH 60V 0.34A 6-Pin SOT-363 T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 14 Weeks Date Code: 2507 | Europe - 9000 |
|
$0.0272 / $0.0558 | Buy Now |
|
DISTI #
87811709
|
Verical | Trans MOSFET N-CH 60V 0.34A 6-Pin SOT-363 T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Date Code: 2507 | Americas - 9000 |
|
$0.0272 / $0.0558 | Buy Now |
|
|
Bristol Electronics | 1070 |
|
RFQ | ||
|
|
Bristol Electronics | Min Qty: 20 | 419 |
|
$0.0788 / $0.2625 | Buy Now |
|
|
Bristol Electronics | Min Qty: 20 | 302 |
|
$0.1313 / $0.2625 | Buy Now |
|
|
Quest Components | SMALL SIGNAL FIELD-EFFECT TRANSISTOR, 0.115A I(D), 60V, 2-ELEMENT, N-CHANNEL, SILICON, METAL-OXIDE SEMICONDUCTOR FET | 755 |
|
$0.0749 / $0.1664 | Buy Now |
|
|
Quest Components | SMALL SIGNAL FIELD-EFFECT TRANSISTOR, 0.115A I(D), 60V, 2-ELEMENT, N-CHANNEL, SILICON, METAL-OXIDE SEMICONDUCTOR FET | 576 |
|
$0.0700 / $0.3500 | Buy Now |
Part Details for 2N7002DW-TP
2N7002DW-TP CAD Models
2N7002DW-TP Part Data Attributes
|
|
2N7002DW-TP
Micro Commercial Components
Buy Now
Datasheet
|
Compare Parts:
2N7002DW-TP
Micro Commercial Components
Small Signal Field-Effect Transistor, 0.115A I(D), 60V, 2-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, ROHS COMPLIANT, PLASTIC PACKAGE-6
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | MICRO COMMERCIAL COMPONENTS CORP | |
| Package Description | SOT-363, 6 PIN | |
| Pin Count | 6 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Samacsys Manufacturer | MCC | |
| Configuration | SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 60 V | |
| Drain Current-Max (ID) | 0.34 A | |
| Drain-source On Resistance-Max | 3 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| Feedback Cap-Max (Crss) | 5 pF | |
| JESD-30 Code | R-PDSO-G6 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 2 | |
| Number of Terminals | 6 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity/Channel Type | N-CHANNEL | |
| Power Dissipation-Max (Abs) | 0.3 W | |
| Qualification Status | Not Qualified | |
| Surface Mount | YES | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 10 | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON |
Alternate Parts for 2N7002DW-TP
This table gives cross-reference parts and alternative options found for 2N7002DW-TP. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of 2N7002DW-TP, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| 2N7002DW | Formosa Microsemi Co Ltd | Check for Price | Small Signal Field-Effect Transistor | 2N7002DW-TP vs 2N7002DW |
| 2N7002DW-R2-10001 | PanJit Semiconductor | Check for Price | Transistor | 2N7002DW-TP vs 2N7002DW-R2-10001 |
