Capacitors / Fixed Capacitors / 293D226X9016C2WE3
Datasheets
293D226X9016C2WE3 by:

Tantalum Capacitor, Polarized, Tantalum (dry/solid), 16V, 10% +Tol, 10% -Tol, 22uF, Surface Mount, 2312, CHIP

Part Details for 293D226X9016C2WE3 by Vishay Intertechnologies

Results Overview of 293D226X9016C2WE3 by Vishay Intertechnologies

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Energy and Power Systems

293D226X9016C2WE3 Information

293D226X9016C2WE3 by Vishay Intertechnologies is a Fixed Capacitor.
Fixed Capacitors are under the broader part category of Capacitors.

A capacitor is a passive electronic component that stores energy. Capacitors are commonly used for energy storage, voltage suppression, and signal filtering. Read more about Capacitors on our Capacitors part category page.

Price & Stock for 293D226X9016C2WE3

Part # Distributor Description Stock Price Buy
DISTI # 37AJ7781
Newark Cap, 22Uf, 16V, Tant, Case C, Capacitance:22Μf, Voltage(Dc):16V, Capacitor Case/Package:2312 [6032 Metric], Capacitance Tolerance:± 10%, Esr:1.4Ohm, Manufacturer Size Code:C, Failure Rate:-, Ripple Current:280Ma, Product Length:6Mmrohs Compliant: Yes |Vishay 293D226X9016C2WE3 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape 1391
  • 1 $0.2060
  • 25 $0.2060
  • 50 $0.2060
  • 100 $0.2060
$0.2060 Buy Now
DISTI # 09K6244
Newark Capacitor,22Uf,16Vdc,10-% Tol,10+% Tol Rohs Compliant: Yes |Vishay 293D226X9016C2WE3 RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel 0
  • 1 $0.3440
  • 5,000 $0.3370
  • 10,000 $0.3140
  • 20,000 $0.2950
  • 30,000 $0.2770
  • 50,000 $0.2670
$0.2670 / $0.3440 Buy Now
DISTI # 37AJ7781
Avnet Americas 293D226X9016C2We3 - Product that comes on tape, but is not reeled (Alt: 37AJ7781) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 13 Weeks, 3 Days Container: Ammo Pack 1391 Partner Stock
  • 1 $0.9900
  • 25 $0.6120
  • 50 $0.4590
  • 100 $0.4110
  • 250 $0.3710
$0.3710 / $0.9900 Buy Now
DISTI # 293D226X9016C2WE3
Avnet Americas 293D226X9016C2We3 - Tape and Reel (Alt: 293D226X9016C2WE3) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 13 Weeks, 0 Days Container: Reel 0
  • 3,000 $0.1260
  • 6,000 $0.1240
  • 12,000 $0.1219
  • 18,000 $0.1200
  • 24,000 $0.1186
$0.1186 / $0.1260 Buy Now
DISTI # 71-293D226X9016C2WE3
Mouser Electronics Tantalum Capacitors - Solid SMD Molded Tantalum Chip Capacitors RoHS: Compliant 0
  • 1 $0.8600
  • 10 $0.5490
  • 100 $0.3890
  • 500 $0.3530
  • 1,000 $0.3280
  • 3,000 $0.3000
  • 6,000 $0.2820
  • 9,000 $0.2620
  • 24,000 $0.2500
$0.2500 / $0.8600 Order Now
Future Electronics 293D Series 22 uF ±10 % 16 V SMT Standard Molded Tantalum Capacitor RoHS: Compliant pbFree: Yes Min Qty: 3000 Package Multiple: 3000 Lead time: 13 Weeks Container: Reel 3000
Reel
  • 3,000 $0.1010
  • 6,000 $0.0990
  • 9,000 $0.0979
  • 12,000 $0.0972
  • 15,000 $0.0950
$0.0950 / $0.1010 Buy Now
Future Electronics 293D Series 22 uF �10 % 16 V SMT Standard Molded Tantalum Capacitor Min Qty: 3000 Package Multiple: 3000 3000
null
  • 3,000 $0.1010
  • 6,000 $0.0990
  • 9,000 $0.0979
  • 12,000 $0.0972
  • 15,000 $0.0950
$0.0950 / $0.1010 Buy Now
DISTI # 293D226X9016C2WE3
Avnet Abacus 293D226X9016C2We3 - Tape and Reel (Alt: 293D226X9016C2WE3) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 15 Weeks, 0 Days Container: Reel Abacus - 0
Buy Now
LCSC Tantalum Capacitors ROHS 2815
  • 5 $0.2932
  • 50 $0.2301
  • 150 $0.2031
  • 500 $0.1693
  • 3,000 $0.1543
  • 6,000 $0.1453
$0.1453 / $0.2932 Buy Now

Part Details for 293D226X9016C2WE3

293D226X9016C2WE3 CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

293D226X9016C2WE3 Part Data Attributes

Parametric Data
293D226X9016C2WE3 Vishay Intertechnologies
Buy Now Datasheet
Compare Parts:
293D226X9016C2WE3 Vishay Intertechnologies Tantalum Capacitor, Polarized, Tantalum (dry/solid), 16V, 10% +Tol, 10% -Tol, 22uF, Surface Mount, 2312, CHIP
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer VISHAY INTERTECHNOLOGY INC
Package Description CHIP
Reach Compliance Code compliant
Factory Lead Time 13 Weeks, 3 Days
Samacsys Manufacturer Vishay
Additional Feature ESR AND RIPPLE CURRENT IS MEASURED AT 100KHZ
Capacitance 22 µF
Capacitor Type TANTALUM CAPACITOR
Dielectric Material TANTALUM (DRY/SOLID)
ESR 1400 mΩ
Height 2.5 mm
JESD-609 Code e3
Leakage Current 0.0035 mA
Length 6 mm
Mounting Feature SURFACE MOUNT
Negative Tolerance 10%
Number of Terminals 2
Operating Temperature-Max 125 °C
Operating Temperature-Min -55 °C
Package Shape RECTANGULAR PACKAGE
Package Style SMT
Packing Method TR, Embossed Plastic, 13 Inch
Polarity POLARIZED
Positive Tolerance 10%
Rated (DC) Voltage (URdc) 16 V
Ripple Current 280 mA
Size Code 2312
Surface Mount YES
Tan Delta 0.06
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Terminal Shape J BEND
Width 3.2 mm

Alternate Parts for 293D226X9016C2WE3

This table gives cross-reference parts and alternative options found for 293D226X9016C2WE3. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of 293D226X9016C2WE3, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
T493C226K016CH652CWAFL KEMET Corporation Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 16V, 10% +Tol, 10% -Tol, 22uF, 2412, 293D226X9016C2WE3 vs T493C226K016CH652CWAFL
T496C226K016CC612AWAFL KEMET Corporation Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 16V, 10% +Tol, 10% -Tol, 22uF, 2412, 293D226X9016C2WE3 vs T496C226K016CC612AWAFL
T496C226K016CC632A7280 KEMET Corporation Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 16V, 10% +Tol, 10% -Tol, 22uF, 2412, 293D226X9016C2WE3 vs T496C226K016CC632A7280
T493C226K016CC611A7280 KEMET Corporation Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 16V, 10% +Tol, 10% -Tol, 22uF, 2412, 293D226X9016C2WE3 vs T493C226K016CC611A7280
T496C226K016CT652C7640 KEMET Corporation Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 16V, 10% +Tol, 10% -Tol, 22uF, 2412, 293D226X9016C2WE3 vs T496C226K016CT652C7640
T496C226K016CC642A7610 KEMET Corporation Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 16V, 10% +Tol, 10% -Tol, 22uF, 2412, 293D226X9016C2WE3 vs T496C226K016CC642A7610
T493C226K016CC652BWAFL KEMET Corporation Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 16V, 10% +Tol, 10% -Tol, 22uF, 2412, 293D226X9016C2WE3 vs T493C226K016CC652BWAFL
T496C226K016AH64207610 KEMET Corporation Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 16V, 10% +Tol, 10% -Tol, 22uF, 2412, 293D226X9016C2WE3 vs T496C226K016AH64207610
T496C226K016CC652A7610 KEMET Corporation Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 16V, 10% +Tol, 10% -Tol, 22uF, 2412, 293D226X9016C2WE3 vs T496C226K016CC652A7610
T493C226K016CH612AWAFL KEMET Corporation Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 16V, 10% +Tol, 10% -Tol, 22uF, 2412, 293D226X9016C2WE3 vs T493C226K016CH612AWAFL

293D226X9016C2WE3 Related Parts

293D226X9016C2WE3 Frequently Asked Questions (FAQ)

  • The recommended soldering temperature for the 293D226X9016C2WE3 is 260°C (500°F) for a maximum of 10 seconds.

  • Yes, the 293D226X9016C2WE3 is a high-reliability capacitor designed for use in demanding applications, including aerospace, defense, and industrial systems.

  • The ESR of the 293D226X9016C2WE3 is typically around 1.5 ohms at 100 kHz, but this value can vary depending on the frequency and operating conditions.

  • Yes, the 293D226X9016C2WE3 is designed to withstand high-vibration environments and meets the requirements of MIL-STD-202, Method 204, Condition D.

  • Yes, the 293D226X9016C2WE3 is RoHS and REACH compliant, making it suitable for use in environmentally friendly designs.
