3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for 293D225X0035B2WE3 by Vishay Intertechnologies
Results Overview of 293D225X0035B2WE3 by Vishay Intertechnologies
- Distributor Offerings: (3 listings)
- Number of FFF Equivalents: (10 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Energy and Power Systems
293D225X0035B2WE3 Information
293D225X0035B2WE3 by Vishay Intertechnologies is a Fixed Capacitor.
Fixed Capacitors are under the broader part category of Capacitors.
A capacitor is a passive electronic component that stores energy. Capacitors are commonly used for energy storage, voltage suppression, and signal filtering. Read more about Capacitors on our Capacitors part category page.
Price & Stock for 293D225X0035B2WE3
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
293D225X0035B2WE3
|
Avnet Americas | 293D225X0035B2We3 - Tape and Reel (Alt: 293D225X0035B2WE3) RoHS: Compliant Min Qty: 8000 Package Multiple: 8000 Lead time: 13 Weeks, 0 Days Container: Reel | 0 |
|
$0.0860 / $0.0914 | Buy Now |
|
DISTI #
74-293D225X0035B2WE3
|
Mouser Electronics | Tantalum Capacitors - Solid SMD 225uF 35volts 20% RoHS: Compliant | 0 |
|
$0.2390 / $0.2520 | Order Now |
|
DISTI #
293D225X0035B2WE3
|
Avnet Abacus | 293D225X0035B2We3 - Tape and Reel (Alt: 293D225X0035B2WE3) RoHS: Compliant Min Qty: 8000 Package Multiple: 8000 Lead time: 15 Weeks, 0 Days Container: Reel | Abacus - 0 |
|
Buy Now |
Part Details for 293D225X0035B2WE3
293D225X0035B2WE3 CAD Models
293D225X0035B2WE3 Part Data Attributes
|
|
293D225X0035B2WE3
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
293D225X0035B2WE3
Vishay Intertechnologies
Tantalum Capacitor, Polarized, Tantalum (dry/solid), 35V, 20% +Tol, 20% -Tol, 2.2uF, Surface Mount, 1411, CHIP
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 12 Weeks | |
| Samacsys Manufacturer | Vishay | |
| Additional Feature | ESR AND RIPPLE CURRENT IS MEASURED AT 100KHZ | |
| Capacitance | 2.2 µF | |
| Capacitor Type | TANTALUM CAPACITOR | |
| Dielectric Material | TANTALUM (DRY/SOLID) | |
| ESR | 3800 mΩ | |
| Height | 1.9 mm | |
| JESD-609 Code | e3 | |
| Leakage Current | 0.0008 mA | |
| Length | 3.5 mm | |
| Mounting Feature | SURFACE MOUNT | |
| Negative Tolerance | 20% | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Shape | RECTANGULAR PACKAGE | |
| Package Style | SMT | |
| Packing Method | TR, Embossed Plastic, 13 Inch | |
| Polarity | POLARIZED | |
| Positive Tolerance | 20% | |
| Rated (DC) Voltage (URdc) | 35 V | |
| Ripple Current | 150 mA | |
| Size Code | 1411 | |
| Surface Mount | YES | |
| Tan Delta | 0.06 | |
| Terminal Finish | MATTE TIN | |
| Terminal Shape | J BEND | |
| Width | 2.8 mm |
Alternate Parts for 293D225X0035B2WE3
This table gives cross-reference parts and alternative options found for 293D225X0035B2WE3. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of 293D225X0035B2WE3, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| TBJB225M035JGSZ0845 | Kyocera AVX Components | Check for Price | Tantalum Capacitor, Polarized, Tantalum, 35V, 20% +Tol, 20% -Tol, 2.2uF, 1411, | 293D225X0035B2WE3 vs TBJB225M035JGSZ0845 |
| TBJB225M035RDSC0924 | Kyocera AVX Components | Check for Price | Tantalum Capacitor, Polarized, Tantalum, 35V, 20% +Tol, 20% -Tol, 2.2uF, 1411, | 293D225X0035B2WE3 vs TBJB225M035RDSC0924 |
| TBJB225M035RGSB0724 | Kyocera AVX Components | Check for Price | Tantalum Capacitor, Polarized, Tantalum, 35V, 20% +Tol, 20% -Tol, 2.2uF, 1411, | 293D225X0035B2WE3 vs TBJB225M035RGSB0724 |
| T493B225M035AB6223 | KEMET Corporation | Check for Price | Tantalum Capacitor, Tantalum (dry/solid), | 293D225X0035B2WE3 vs T493B225M035AB6223 |
| T493B225M035AB6432 | KEMET Corporation | Check for Price | Tantalum Capacitor, Tantalum (dry/solid), | 293D225X0035B2WE3 vs T493B225M035AB6432 |
| T493B225M035AH61207610 | KEMET Corporation | Check for Price | Tantalum Capacitor, Tantalum (dry/solid), | 293D225X0035B2WE3 vs T493B225M035AH61207610 |
| T493B225M035AT6232 | KEMET Corporation | Check for Price | Tantalum Capacitor, Tantalum (dry/solid), | 293D225X0035B2WE3 vs T493B225M035AT6232 |
| TBJB225M035CCLB9000 | Kyocera AVX Components | Check for Price | Tantalum Capacitor, Polarized, Tantalum, 35V, 20% +Tol, 20% -Tol, 2.2uF, 1411, | 293D225X0035B2WE3 vs TBJB225M035CCLB9000 |
| T493B225M035CB651C7610 | KEMET Corporation | Check for Price | Tantalum Capacitor, Polarized, Tantalum (dry/solid), 35V, 20% +Tol, 20% -Tol, 2.2uF, 1411, | 293D225X0035B2WE3 vs T493B225M035CB651C7610 |
| TBJB225M035CGDD0845 | Kyocera AVX Components | Check for Price | Tantalum Capacitor, Polarized, Tantalum, 35V, 20% +Tol, 20% -Tol, 2.2uF, 1411, | 293D225X0035B2WE3 vs TBJB225M035CGDD0845 |
