293D105X0016A2TE3 by:

Tantalum Capacitor, Polarized, Tantalum (dry/solid), 16V, 20% +Tol, 20% -Tol, 1uF, Surface Mount, 1206, CHIP

Part Details for 293D105X0016A2TE3 by Vishay Intertechnologies

Results Overview of 293D105X0016A2TE3 by Vishay Intertechnologies

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Energy and Power Systems

293D105X0016A2TE3 Information

293D105X0016A2TE3 by Vishay Intertechnologies is a Fixed Capacitor.
Fixed Capacitors are under the broader part category of Capacitors.

A capacitor is a passive electronic component that stores energy. Capacitors are commonly used for energy storage, voltage suppression, and signal filtering. Read more about Capacitors on our Capacitors part category page.

Price & Stock for 293D105X0016A2TE3

Part # Distributor Description Stock Price Buy
DISTI # 69AH4619
Newark Cap, 1Uf, 16V, Tant, Case A Rohs Compliant: Yes |Vishay 293D105X0016A2TE3 RoHS: Compliant Min Qty: 2000 Package Multiple: 1 Date Code: 1 Container: Reel 2000
  • 2,000 $0.0890
  • 4,000 $0.0840
  • 8,000 $0.0790
  • 12,000 $0.0790
$0.0790 / $0.0890 Buy Now
DISTI # 40Y2996
Newark Surface Mount Tantalum Capacitor, Tantamountr, 293D Series, 1 F, 20%, 16 V, 1206 [3216 Metric] Rohs Compliant: Yes |Vishay 293D105X0016A2TE3 RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape 272
  • 1 $0.3100
$0.3100 Buy Now
DISTI # 293D105X0016A2TE3
Avnet Americas Surface Mount Tantalum Capacitor, 1 ?F, 16 V, 1206 [3216 Metric], ? 20%, 9.3 ohm, A - Tape and Reel (Alt: 293D105X0016A2TE3) RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Lead time: 13 Weeks, 0 Days Container: Reel 0
  • 2,000 $0.0442
  • 4,000 $0.0440
  • 8,000 $0.0437
  • 12,000 $0.0435
  • 16,000 $0.0433
$0.0433 / $0.0442 Buy Now
DISTI # 74-293D105X0016A2TE3
Mouser Electronics Tantalum Capacitors - Solid SMD 1uF 16volts 20% A case Molded RoHS: Compliant 4234
  • 1 $0.5800
  • 10 $0.3980
  • 100 $0.2710
  • 500 $0.2220
  • 1,000 $0.2050
  • 2,000 $0.1860
  • 10,000 $0.1600
  • 24,000 $0.1520
  • 50,000 $0.1440
$0.1440 / $0.5800 Buy Now
DISTI # E02:0323_01683236
Arrow Electronics Cap Tant Solid 1uF 16V A CASE 20%( 3.2 X 1.6 X 1.6mm) Inward L SMD 3216-18 9.3 Ohm 125°C T/R RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Lead time: 13 Weeks Date Code: 2435 Europe - 12000
  • 2,000 $0.0801
  • 4,000 $0.0697
  • 6,000 $0.0691
  • 10,000 $0.0468
$0.0468 / $0.0801 Buy Now
DISTI # V72:2272_07466515
Arrow Electronics Cap Tant Solid 1uF 16V A CASE 20%( 3.2 X 1.6 X 1.6mm) Inward L SMD 3216-18 9.3 Ohm 125°C T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 13 Weeks Date Code: 2041 Container: Cut Strips Americas - 2134
  • 1 $0.0656
  • 10 $0.0640
  • 25 $0.0623
  • 100 $0.0607
  • 250 $0.0590
  • 500 $0.0574
  • 1,000 $0.0558
$0.0558 / $0.0656 Buy Now
Future Electronics 293D Series 1 uF ±20 % 16 V Surface Mount Standard Molded Tantalum Capacitor RoHS: Compliant pbFree: Yes Min Qty: 2000 Package Multiple: 2000 Lead time: 13 Weeks Container: Reel 226000
Reel
  • 2,000 $0.0467
  • 6,000 $0.0454
  • 8,000 $0.0451
  • 20,000 $0.0441
  • 30,000 $0.0432
$0.0432 / $0.0467 Buy Now
DISTI # 77274627
Verical Cap Tant Solid 1uF 16V A CASE 20%( 3.2 X 1.6 X 1.6mm) Inward L SMD 3216-18 9.3 Ohm 125°C T/R RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Date Code: 2331 Americas - 56000
  • 2,000 $0.0776
  • 28,000 $0.0709
  • 42,000 $0.0660
  • 56,000 $0.0622
$0.0622 / $0.0776 Buy Now
DISTI # 86938588
Verical Cap Tant Solid 1uF 16V A CASE 20%( 3.2 X 1.6 X 1.6mm) Inward L SMD 3216-18 9.3 Ohm 125°C T/R RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Date Code: 2435 Americas - 12000
  • 2,000 $0.0803
  • 4,000 $0.0699
  • 6,000 $0.0694
  • 10,000 $0.0470
$0.0470 / $0.0803 Buy Now
DISTI # 51963329
Verical Cap Tant Solid 1uF 16V A CASE 20%( 3.2 X 1.6 X 1.6mm) Inward L SMD 3216-18 9.3 Ohm 125°C T/R RoHS: Compliant Min Qty: 106 Package Multiple: 1 Date Code: 2041 Americas - 2134
  • 106 $0.0607
  • 250 $0.0590
  • 500 $0.0574
  • 1,000 $0.0558
$0.0558 / $0.0607 Buy Now
Bristol Electronics   5399
RFQ
Bristol Electronics   612
RFQ
Quest Components CAP,TANTALUM / TA2O5,1UF,16VDC,20-% TOL,20+% TOL 3412
  • 1 $1.0000
  • 112 $0.3000
  • 1,334 $0.2000
$0.2000 / $1.0000 Buy Now
Quest Components CAP,TANTALUM / TA2O5,1UF,16VDC,20-% TOL,20+% TOL 1600
  • 1 $0.3610
  • 36 $0.1625
  • 309 $0.1083
$0.1083 / $0.3610 Buy Now
DISTI # 293D105X0016A2TE3
TTI Tantalum Capacitors - Solid SMD 1uF 16volts 20% A case Molded RoHS: Compliant pbFree: Pb-Free Min Qty: 2000 Package Multiple: 2000 Container: Reel Americas - 8000
In Stock
  • 2,000 $0.0720
  • 4,000 $0.0680
  • 6,000 $0.0670
  • 10,000 $0.0630
  • 20,000 $0.0620
  • 30,000 $0.0600
$0.0600 / $0.0720 Buy Now
Future Electronics 293D Series 1 uF �20 % 16 V Surface Mount Standard Molded Tantalum Capacitor Min Qty: 2000 Package Multiple: 2000 226000
null
  • 2,000 $0.0467
  • 6,000 $0.0454
  • 8,000 $0.0451
  • 20,000 $0.0441
  • 30,000 $0.0432
$0.0432 / $0.0467 Buy Now
DISTI # 293D105X0016A2TE3
TME Capacitor: tantalum, 1uF, 16VDC, SMD, A, 1206, ±20%, -55÷125°C Min Qty: 1 3651
  • 1 $0.3314
  • 5 $0.2241
  • 10 $0.1953
  • 50 $0.1434
  • 100 $0.1256
  • 250 $0.1052
  • 500 $0.0918
  • 1,000 $0.0800
  • 2,000 $0.0696
  • 18,000 $0.0608
$0.0608 / $0.3314 Buy Now
DISTI # 293D105X0016A2TE3
IBS Electronics SURFACE MOUNT TANTALUM CAPACITOR 1 UF 16 V &#xB1, 20% -55 &#xB0, C 125 &#xB0, C 1206 [3216-18 METRIC] Min Qty: 2000 Package Multiple: 1 226000
  • 2,000 $0.0607
  • 6,000 $0.0590
  • 8,000 $0.0586
  • 20,000 $0.0573
  • 30,000 $0.0562
$0.0562 / $0.0607 Buy Now
DISTI # KTA6717
Rutronik TC 1,0uF 16V 20% Case A RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Container: Reel Stock DE - 18000
Stock HK - 0
Stock US - 0
Stock SG - 0
  • 2,000 $0.0612
  • 4,000 $0.0581
  • 6,000 $0.0576
  • 12,000 $0.0571
  • 18,000 $0.0545
$0.0545 / $0.0612 Buy Now
DISTI # 293D105X0016A2TE3
Avnet Abacus Surface Mount Tantalum Capacitor 1 F 16 V 1206 3216 Metric 20 93 ohm A - Tape and Reel (Alt: 293D105X0016A2TE3) RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Lead time: 15 Weeks, 0 Days Container: Reel Abacus - 18000
Buy Now
Component Electronics, Inc IN STOCK SHIP TODAY 1040
  • 1 $0.3800
  • 100 $0.2900
  • 1,000 $0.2500
$0.2500 / $0.3800 Buy Now
Vyrian Capacitors 33920
RFQ

Part Details for 293D105X0016A2TE3

293D105X0016A2TE3 CAD Models

293D105X0016A2TE3 Part Data Attributes

293D105X0016A2TE3 Vishay Intertechnologies
Buy Now Datasheet
Compare Parts:
293D105X0016A2TE3 Vishay Intertechnologies Tantalum Capacitor, Polarized, Tantalum (dry/solid), 16V, 20% +Tol, 20% -Tol, 1uF, Surface Mount, 1206, CHIP
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer VISHAY INTERTECHNOLOGY INC
Package Description CHIP
Reach Compliance Code compliant
Factory Lead Time 12 Weeks
Samacsys Manufacturer Vishay
Additional Feature ESR AND RIPPLE CURRENT IS MEASURED AT 100KHZ
Capacitance 1 µF
Capacitor Type TANTALUM CAPACITOR
Dielectric Material TANTALUM (DRY/SOLID)
ESR 9300 mΩ
Height 1.6 mm
JESD-609 Code e3
Leakage Current 0.0005 mA
Length 3.2 mm
Mounting Feature SURFACE MOUNT
Negative Tolerance 20%
Number of Terminals 2
Operating Temperature-Max 125 °C
Operating Temperature-Min -55 °C
Package Shape RECTANGULAR PACKAGE
Package Style SMT
Packing Method TR, Embossed Plastic, 7 Inch
Polarity POLARIZED
Positive Tolerance 20%
Rated (DC) Voltage (URdc) 16 V
Ripple Current 90 mA
Size Code 1206
Surface Mount YES
Tan Delta 0.04
Terminal Finish MATTE TIN OVER NICKEL
Terminal Shape J BEND
Width 1.6 mm

Alternate Parts for 293D105X0016A2TE3

This table gives cross-reference parts and alternative options found for 293D105X0016A2TE3. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of 293D105X0016A2TE3, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
TBJA105M016RGLZ0023 Kyocera AVX Components Check for Price Tantalum Capacitor, Polarized, Tantalum, 16V, 20% +Tol, 20% -Tol, 1uF, 1206, 293D105X0016A2TE3 vs TBJA105M016RGLZ0023
TBJA105M016RFLC0H45 Kyocera AVX Components Check for Price Tantalum Capacitor, Polarized, Tantalum, 16V, 20% +Tol, 20% -Tol, 1uF, 1206, 293D105X0016A2TE3 vs TBJA105M016RFLC0H45
T493A105M016CB62107280 KEMET Corporation Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 16V, 20% +Tol, 20% -Tol, 1uF, Surface Mount, 1206, CHIP 293D105X0016A2TE3 vs T493A105M016CB62107280
TBJA105M016RWLB0900 Kyocera AVX Components Check for Price Tantalum Capacitor, Polarized, Tantalum, 16V, 20% +Tol, 20% -Tol, 1uF, Surface Mount, 1206, CHIP 293D105X0016A2TE3 vs TBJA105M016RWLB0900
TBJA105M016RGSZ0745 Kyocera AVX Components Check for Price Tantalum Capacitor, Polarized, Tantalum, 16V, 20% +Tol, 20% -Tol, 1uF, 1206, 293D105X0016A2TE3 vs TBJA105M016RGSZ0745
TBJA105M016RGLC0745 Kyocera AVX Components Check for Price Tantalum Capacitor, Polarized, Tantalum, 16V, 20% +Tol, 20% -Tol, 1uF, 1206, 293D105X0016A2TE3 vs TBJA105M016RGLC0745
T493A105M016BM6210 KEMET Corporation Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 16V, 20% +Tol, 20% -Tol, 1uF, 1206 293D105X0016A2TE3 vs T493A105M016BM6210
SK-1C105M-RA Lelon Electronics Corp Check for Price CAP,TANTALUM / TA2O5,1UF,16VDC,20% -TOL,20% +TOL 293D105X0016A2TE3 vs SK-1C105M-RA
TBJA105M016RRSB0723 Kyocera AVX Components Check for Price Tantalum Capacitor, Polarized, Tantalum, 16V, 20% +Tol, 20% -Tol, 1uF, Surface Mount, 1206, CHIP 293D105X0016A2TE3 vs TBJA105M016RRSB0723
TBJA105M016CRLZ0945 Kyocera AVX Components Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 16V, 20% +Tol, 20% -Tol, 1uF, Surface Mount, 1206, CHIP 293D105X0016A2TE3 vs TBJA105M016CRLZ0945

293D105X0016A2TE3 Related Parts

293D105X0016A2TE3 Frequently Asked Questions (FAQ)

  • The recommended soldering temperature for the 293D105X0016A2TE3 capacitor is between 260°C to 280°C for a maximum of 10 seconds.

  • Yes, the 293D105X0016A2TE3 capacitor is designed for high-reliability applications and meets the requirements of MIL-PRF-123 and MIL-PRF-39003.

  • The maximum voltage derating for the 293D105X0016A2TE3 capacitor is 50% of the rated voltage at 125°C.

  • Yes, the 293D105X0016A2TE3 capacitor is suitable for high-frequency applications up to 1 GHz due to its low equivalent series resistance (ESR) and high self-resonant frequency.

  • Yes, the 293D105X0016A2TE3 capacitor is compatible with lead-free soldering processes and meets the requirements of RoHS and WEEE directives.
