Memory / EEPROMs / 24AA512T-I/ST
Datasheets
24AA512T-I/ST by: Microchip Technology Inc

64K X 8 I2C/2-WIRE SERIAL EEPROM, PDSO8, 4.40 MM, ROHS COMPLIANT, PLASTIC, TSSOP-8

Part Details for 24AA512T-I/ST by Microchip Technology Inc

Results Overview of 24AA512T-I/ST by Microchip Technology Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

24AA512T-I/ST Information

24AA512T-I/ST by Microchip Technology Inc is an EEPROM.
EEPROMs are under the broader part category of Memory Components.

Memory components are essential in electronics for computer processing. They can be volatile or non-volatile, depending on the desired function. Read more about Memory Components on our Memory part category page.

Price & Stock for 24AA512T-I/ST

Part # Distributor Description Stock Price Buy
DISTI # 08R2174
Newark 512K, 64K X 8, 1.8V Ser Ee, Ind 8 Tssop 4.4Mm T/R Rohs Compliant: Yes |Microchip 24AA512T-I/ST RoHS: Compliant Min Qty: 2500 Package Multiple: 1 Date Code: 0 Container: Reel 0
  • 2,500 $1.6800
$1.6800 Buy Now
DISTI # 24AA512T-I/STCT-ND
DigiKey IC EEPROM 512KBIT I2C 8TSSOP Min Qty: 1 Lead time: 11 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) 2842
In Stock
  • 1 $2.0000
  • 2,500 $1.6866
$1.6866 / $2.0000 Buy Now
DISTI # 24AA512T-I/ST
Avnet Americas EEPROM Serial-I2C 512K-bit 64K x 8 2.5V/3.3V/5V 8-Pin TSSOP T/R - Tape and Reel (Alt: 24AA512T-I/ST) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 11 Weeks, 0 Days Container: Reel 0
  • 2,500 $1.6375
  • 5,000 $1.6243
  • 10,000 $1.6111
  • 15,000 $1.5981
  • 20,000 $1.5817
$1.5817 / $1.6375 Buy Now
DISTI # 579-24AA512T-I/ST
Mouser Electronics EEPROM 128K 16K X 8 1.8V SER EE IND RoHS: Compliant 10230
  • 1 $1.7600
  • 25 $1.7000
  • 100 $1.6700
  • 2,500 $1.6700
$1.6700 / $1.7600 Buy Now
DISTI # V72:2272_06422059
Arrow Electronics EEPROM Serial-I2C 512K-bit 64K x 8 1.8V/2.5V/3.3V/5V 8-Pin TSSOP T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 11 Weeks Date Code: 2235 Container: Cut Strips Americas - 1683
  • 1 $1.8510
  • 10 $1.8230
  • 25 $1.7940
  • 100 $1.7660
  • 250 $1.7370
  • 500 $1.7080
  • 1,000 $1.6800
$1.6800 / $1.8510 Buy Now
DISTI # 24AA512T-I/ST
Microchip Technology Inc 512K, 64K X 8, 1.7V SER EE, IND, TSSOP, Projected EOL: 2034-12-17 COO: China, Philippines, Thailand ECCN: EAR99 RoHS: Compliant Lead time: 11 Weeks, 0 Days Container: Reel 708

Alternates Available
  • 1 $1.7600
  • 25 $1.6900
  • 100 $1.6300
  • 1,000 $1.5400
  • 5,000 $1.4500
$1.4500 / $1.7600 Buy Now
Onlinecomponents.com EEPROM - Serial-I²C - 512Kb (64K x 8) - 1.8/2.5V/3.3V/5V - 8-Pin TSSOP - Tape&Reel RoHS: Compliant Alternative Product Available
  • 625 $4.4500
  • 1,250 $2.3600
  • 1,875 $1.6600
  • 2,500 $1.6300
$1.6300 / $4.4500 Buy Now
DISTI # 65085732
Verical EEPROM Serial-I2C 512K-bit 64K x 8 1.8V/2.5V/3.3V/5V 8-Pin TSSOP T/R RoHS: Compliant Min Qty: 4 Package Multiple: 1 Date Code: 2235 Americas - 1683
  • 4 $1.8510
  • 10 $1.8230
  • 25 $1.7940
  • 100 $1.7660
  • 250 $1.7370
  • 500 $1.7080
  • 1,000 $1.6800
$1.6800 / $1.8510 Buy Now
NAC 512K, 64K X 8, 1.8V SER EE, IND - Package: 8 TSSOP 4.4mm T/R RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 0
  • 1 $2.0200
  • 100 $1.8200
  • 500 $1.6800
  • 1,000 $1.6400
$1.6400 / $2.0200 Buy Now
DISTI # 24AA512T-I/ST
Avnet Silica EEPROM SerialI2C 512Kbit 64K x 8 25V33V5V 8Pin TSSOP TR (Alt: 24AA512T-I/ST) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 13 Weeks, 0 Days Silica - 0
Buy Now
DISTI # 24AA512T-I/ST
EBV Elektronik EEPROM SerialI2C 512Kbit 64K x 8 25V33V5V 8Pin TSSOP TR (Alt: 24AA512T-I/ST) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 12 Weeks, 0 Days EBV - 0
Buy Now
LCSC 400kHz I2C TSSOP-8 EEPROM ROHS 9
  • 1 $5.2080
  • 10 $4.6408
  • 30 $4.3043
  • 100 $3.9634
  • 500 $3.8050
  • 1,000 $3.7341
$3.7341 / $5.2080 Buy Now
Master Electronics EEPROM - Serial-I²C - 512Kb (64K x 8) - 1.8/2.5V/3.3V/5V - 8-Pin TSSOP - Tape&Reel RoHS: Compliant Alternative Product Available
  • 625 $4.4500
  • 1,250 $2.3600
  • 1,875 $1.6600
  • 2,500 $1.6300
$1.6300 / $4.4500 Buy Now
Vyrian Memory ICs 3723
RFQ
Win Source Electronics I2C™ Serial EEPROM Family Data Sheet | IC EEPROM 512K I2C 8TSSOP 1976
  • 22 $2.6588
  • 53 $2.1817
  • 82 $2.1134
  • 113 $2.0453
  • 147 $1.9771
  • 196 $1.7726
$1.7726 / $2.6588 Buy Now

Part Details for 24AA512T-I/ST

24AA512T-I/ST Part Data Attributes

Parametric Data
24AA512T-I/ST Microchip Technology Inc
Buy Now Datasheet
Compare Parts:
24AA512T-I/ST Microchip Technology Inc 64K X 8 I2C/2-WIRE SERIAL EEPROM, PDSO8, 4.40 MM, ROHS COMPLIANT, PLASTIC, TSSOP-8
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer MICROCHIP TECHNOLOGY INC
Part Package Code SOIC
Package Description 4.40 MM, ROHS COMPLIANT, PLASTIC, TSSOP-8
Pin Count 8
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8542.32.00.51
Factory Lead Time 11 Weeks
Samacsys Manufacturer Microchip
Clock Frequency-Max (fCLK) 0.4 MHz
Data Retention Time-Min 200
Endurance 1000000 Write/Erase Cycles
I2C Control Byte 1010DDDR
JESD-30 Code R-PDSO-G8
JESD-609 Code e3
Length 4.4 mm
Memory Density 524288 bit
Memory IC Type EEPROM
Memory Width 8
Moisture Sensitivity Level 1
Number of Functions 1
Number of Terminals 8
Number of Words 65536 words
Number of Words Code 64000
Operating Mode SYNCHRONOUS
Operating Temperature-Max 85 °C
Operating Temperature-Min -40 °C
Organization 64KX8
Package Body Material PLASTIC/EPOXY
Package Code TSSOP
Package Equivalence Code TSSOP8,.25
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Parallel/Serial SERIAL
Peak Reflow Temperature (Cel) 260
Qualification Status Not Qualified
Seated Height-Max 1.2 mm
Serial Bus Type I2C
Standby Current-Max 0.000001 A
Supply Current-Max 0.005 mA
Supply Voltage-Max (Vsup) 5.5 V
Supply Voltage-Min (Vsup) 1.7 V
Supply Voltage-Nom (Vsup) 2.5 V
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish MATTE TIN
Terminal Form GULL WING
Terminal Pitch 0.65 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 60
Width 3 mm
Write Cycle Time-Max (tWC) 5 ms
Write Protection HARDWARE

Alternate Parts for 24AA512T-I/ST

This table gives cross-reference parts and alternative options found for 24AA512T-I/ST. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of 24AA512T-I/ST, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
24AA512-I/MF Microchip Technology Inc $1.5340 64K X 8 I2C/2-WIRE SERIAL EEPROM, PDSO8, 6 X 5 MM, PLASTIC, ROHS COMPLIANT, DFN-8 24AA512T-I/ST vs 24AA512-I/MF
24AA512-I/SM Microchip Technology Inc $1.5774 64K X 8 I2C/2-WIRE SERIAL EEPROM, PDSO8, 5.28 MM, PLASTIC, ROHS COMPLIANT, EIAJ, SOIJ-8 24AA512T-I/ST vs 24AA512-I/SM
24AA512-I/ST Microchip Technology Inc $1.8416 64K X 8 I2C/2-WIRE SERIAL EEPROM, PDSO8, 4.40 MM, ROHS COMPLIANT, PLASTIC, TSSOP-8 24AA512T-I/ST vs 24AA512-I/ST
R1EX24512BSAS0G#S0 Renesas Electronics Corporation Check for Price I2C/2-WIRE SERIAL EEPROM 24AA512T-I/ST vs R1EX24512BSAS0G#S0
M24512-HRMN6TG STMicroelectronics Check for Price 64KX8 I2C/2-WIRE SERIAL EEPROM, PDSO8, 0.150 INCH, ROHS COMPLIANT, PLASTIC, SOP-8 24AA512T-I/ST vs M24512-HRMN6TG
R1EX24512BSAS0I Renesas Electronics Corporation Check for Price 64KX8 I2C/2-WIRE SERIAL EEPROM, PDSO8, 3.90 X 4.89 MM, 1.27 MM PITCH, LEAD FREE, PLASTIC, SOP-8 24AA512T-I/ST vs R1EX24512BSAS0I
M24512-RMN6TP/K STMicroelectronics Check for Price 64KX8 EEPROM 5V, PDSO8, 0.150 INCH, HALOGEN FREE AND ROHS COMPLIANT, PLASTIC, SOP-8 24AA512T-I/ST vs M24512-RMN6TP/K
24AA512T-E/MF Microchip Technology Inc Check for Price 64K X 8 I2C/2-WIRE SERIAL EEPROM, PDSO8, 6 X 5 MM, PLASTIC, ROHS COMPLIANT, DFN-8 24AA512T-I/ST vs 24AA512T-E/MF
R1EX24512BSAS0G#U0 Renesas Electronics Corporation Check for Price EEPROM, SOP, /Embossed Tape 24AA512T-I/ST vs R1EX24512BSAS0G#U0
24AA512-E/P Microchip Technology Inc Check for Price 64K X 8 I2C/2-WIRE SERIAL EEPROM, PDIP8, 0.300 INCH, ROHS COMPLIANT, PLASTIC, DIP-8 24AA512T-I/ST vs 24AA512-E/P

24AA512T-I/ST Related Parts

24AA512T-I/ST Frequently Asked Questions (FAQ)

  • The 24AA512T-I/ST has a minimum of 1 million write cycles, but the actual number of write cycles may vary depending on the application and usage.

  • To ensure data integrity, use the 24AA512T-I/ST's built-in power-on reset (POR) and brown-out detection (BOD) features, and implement a robust power-down sequence in your system design.

  • The recommended operating voltage range for the 24AA512T-I/ST is 2.5V to 5.5V, but it can operate down to 1.8V with reduced performance and reliability.

  • Use the 24AA512T-I/ST's page write and block write commands, and ensure that you follow the recommended write protocols and timing to avoid data corruption and ensure data integrity.

  • The maximum clock frequency for the 24AA512T-I/ST is 1 MHz, but it can operate at lower frequencies depending on the application and system requirements.
