1.27mm (0.05in.) pitch, Receptacle Top entry, 10 contacts

Part Details for 20021311-00010T4LF by Amphenol Communications Solutions

Results Overview of 20021311-00010T4LF by Amphenol Communications Solutions

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Automotive

20021311-00010T4LF Information

20021311-00010T4LF by Amphenol Communications Solutions is a Header and Edge Type Connector.
Headers and Edge Type Connectors are under the broader part category of Connectors.

Connectors are devices that join electrical termination points to form circuits. With various types designed for specific functions like data, power, or signal transmission, choosing the right connector is essential for compatibility and device performance. Read more about Connectors on our Connectors part category page.

Price & Stock for 20021311-00010T4LF

Part # Distributor Description Stock Price Buy
DISTI # 38AH4107
Newark 20021311-00010T4Lf-Rcpt Vt Th Rohs Compliant: Yes |Amphenol Communications Solutions 20021311-00010T4LF RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk 3187
  • 1 $1.1700
  • 10 $0.8790
  • 25 $0.8250
  • 50 $0.7560
  • 100 $0.7030
  • 250 $0.7010
  • 500 $0.7000
  • 1,000 $0.6980
$0.6980 / $1.1700 Buy Now
DISTI # 82R8648
Newark Board-Board Connector, Receptacle, 10 Position, 2Row, Connector Systems:Wire-To-Board, Pitch Spacing:1.27Mm, No. Of Rows:2Rows, No. Of Contacts:10Contacts, Connector Mounting:Through Hole Mount, Contact Material:Copper Alloy Rohs Compliant: Yes |Amphenol Communications Solutions 20021311-00010T4LF RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk 2978
  • 1 $1.1300
  • 10 $1.0700
  • 25 $1.0100
  • 50 $0.9520
  • 100 $0.9130
  • 250 $0.8370
  • 500 $0.7610
  • 1,000 $0.6850
$0.6850 / $1.1300 Buy Now
DISTI # 609-3754-ND
DigiKey CONN RCPT 10POS 0.05 GOLD PCB Min Qty: 1 Lead time: 6 Weeks Container: Tube 2260
In Stock
  • 1 $1.0700
  • 86 $0.7780
  • 172 $0.7408
  • 516 $0.6855
  • 1,032 $0.6528
  • 5,074 $0.5834
  • 10,062 $0.5559
$0.5559 / $1.0700 Buy Now
Future Electronics Dual Row 10 Position 1.27 mm Board to Board Through Hole Female Socket Connector RoHS: Compliant pbFree: Yes Min Qty: 1 Package Multiple: 1 Lead time: 17 Weeks Container: Tube 36
Tube
  • 1 $0.5700
  • 50 $0.5600
  • 200 $0.5450
  • 500 $0.5350
  • 2,000 $0.5050
$0.5050 / $0.5700 Buy Now
Onlinecomponents.com Conn Socket Strip RCP 10 POS 1.27mm Solder ST Thru-Hole Tube RoHS: Compliant 5676 In Stock
  • 86 $0.6800
  • 258 $0.6460
  • 516 $0.5970
  • 1,032 $0.5640
  • 2,580 $0.5220
  • 5,074 $0.5190
  • 7,568 $0.5170
  • 10,062 $0.5140
$0.5140 / $0.6800 Buy Now
Future Electronics Dual Row 10 Position 1.27 mm Board to Board Through Hole Female Socket Connector Min Qty: 1 Package Multiple: 1 36
null
  • 1 $0.5700
  • 50 $0.5600
  • 200 $0.5450
  • 500 $0.5350
  • 2,000 $0.5050
$0.5050 / $0.5700 Buy Now
DISTI # 20021311-00010T4LF
TME connector 20021311-00010T4LF Min Qty: 1 110
  • 1 $0.9400
  • 5 $0.8500
  • 20 $0.7600
  • 100 $0.6600
$0.6600 / $0.9400 Buy Now
LCSC 1.27mm 1.27mm Double Row Tin 10P Phosphor Bronze -40+105 Straight 4.4mm Square Hole PluginP1.27mm Female Headers ROHS 2507
  • 1 $1.0410
  • 10 $0.8691
  • 30 $0.7755
  • 100 $0.6684
  • 500 $0.6216
  • 1,000 $0.5990
$0.5990 / $1.0410 Buy Now
Master Electronics Conn Socket Strip RCP 10 POS 1.27mm Solder ST Thru-Hole Tube RoHS: Compliant 5676 In Stock
  • 86 $0.6800
  • 258 $0.6460
  • 516 $0.5970
  • 1,032 $0.5640
  • 2,580 $0.5220
  • 5,074 $0.5190
  • 7,568 $0.5170
  • 10,062 $0.5140
$0.5140 / $0.6800 Buy Now

Part Details for 20021311-00010T4LF

20021311-00010T4LF CAD Models

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

20021311-00010T4LF Part Data Attributes

Parametric Data
20021311-00010T4LF Amphenol Communications Solutions
Buy Now Datasheet
Compare Parts:
20021311-00010T4LF Amphenol Communications Solutions 1.27mm (0.05in.) pitch, Receptacle Top entry, 10 contacts
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer AMPHENOL COMMUNICATIONS SOLUTIONS
Package Description LEAD FREE
Pin Count 10
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8536.69.40.40
Samacsys Manufacturer Amphenol Communications Solutions
Body Breadth 0.118 inch
Body Depth 0.173 inch
Body Length 0.268 inch
Body/Shell Style RECEPTACLE
Connector Type BOARD CONNECTOR
Contact Finish Mating NOT SPECIFIED
Contact Finish Termination MATTE TIN OVER NICKEL
Contact Gender FEMALE
Contact Material NOT SPECIFIED
Contact Pattern RECTANGULAR
Contact Resistance 20 mΩ
Contact Style SQ PIN-SKT
DIN Conformance NO
Dielectric Withstanding Voltage 700VAC V
Durability 100 Cycles
Filter Feature NO
IEC Conformance NO
Insertion Force-Max 2.1684 N
Insulation Resistance 1000000000 Ω
Insulator Color BLACK
Insulator Material POLYETHYLENE
JESD-609 Code e3
MIL Conformance NO
Mating Contact Pitch 0.05 inch
Mating Contact Row Spacing 0.05 inch
Mixed Contacts NO
Mounting Option 1 LOCKING
Mounting Style STRAIGHT
Mounting Type BOARD
Number Of Connectors ONE
Number Of PCB Rows 2
Number of Rows Loaded 2
Operating Temperature-Max 105 °C
Operating Temperature-Min -40 °C
Option GENERAL PURPOSE
PCB Contact Pattern RECTANGULAR
PCB Contact Row Spacing 1.27 mm
Plating Thickness 9.8u inch
Rated Current (Signal) 1 A
Reference Standard UL
Terminal Length 0.094 inch
Terminal Pitch 1.27 mm
Termination Type SOLDER
Total Number of Contacts 10
UL Flammability Code 94V-0
Withdrawl Force-Min .199882 N
