Switches / Keypad Switches / 2-1437565-6
Datasheets
2-1437565-6 by: TE Connectivity

KEYPAD SWITCH, SPST, MOMENTARY-TACTILE, 0.05A, 24VDC, 2.06N, THROUGH HOLE-STRAIGHT, ROHS COMPLIANT

Part Details for 2-1437565-6 by TE Connectivity

Results Overview of 2-1437565-6 by TE Connectivity

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Energy and Power Systems Medical Imaging Robotics and Drones

2-1437565-6 Information

2-1437565-6 by TE Connectivity is a Keypad Switch.
Keypad Switches are under the broader part category of Switches.

Electrical switches are binary devices that control the flow of current in a circuit by either allowing or preventing the flow of electrons. Read more about Switches on our Switches part category page.

Price & Stock for 2-1437565-6

Part # Distributor Description Stock Price Buy
DISTI # 4315147
Farnell TACTILE SWITCHES RoHS: Compliant Min Qty: 2000 Lead time: 1 Weeks, 2 Days Container: Each 17000
  • 2,000 $0.1221
  • 6,000 $0.1148
$0.1148 / $0.1221 Buy Now
DISTI # 2-1437565-6
Avnet Americas Switch Tactile OFF (ON) Round Button PC Pins 0.05A 12VDC 1.57N Thru-Hole Radial Tape - Bulk (Alt: 2-1437565-6) RoHS: Compliant Min Qty: 30000 Package Multiple: 10000 Lead time: 19 Weeks, 5 Days Container: Bulk 0
  • 30,000 $0.0578
  • 50,000 $0.0525
  • 80,000 $0.0521
  • 150,000 $0.0482
  • 300,000 $0.0478
$0.0478 / $0.0578 Buy Now
DISTI # AMP2-1437565-6
Heilind Electronics FSM2JRT=PUSHBUTTONS SWITCH Americas - 0 in Stock
  • 30,000 $0.0724
  • 104,000 $0.0619
$0.0619 / $0.0724 Buy Now
Onlinecomponents.com FSM2JRT=PUSHBUTTONS SWITCH RoHS: Compliant 19000 In Stock
  • 1,000 $0.0888
  • 3,000 $0.0710
  • 8,000 $0.0681
  • 25,000 $0.0647
  • 50,000 $0.0593
  • 100,000 $0.0532
  • 150,000 $0.0524
  • 250,000 $0.0516
$0.0516 / $0.0888 Buy Now
DISTI # 87456907
Verical Switch Tactile OFF (ON) SPST Round Button PC Pins 0.05A 24VDC 1.57N Thru-Hole T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 1000 Date Code: 2149 Americas - 8000
  • 3,000 $0.0854
  • 6,000 $0.0742
$0.0742 / $0.0854 Buy Now
DISTI # 87336575
Verical Switch Tactile OFF (ON) SPST Round Button PC Pins 0.05A 24VDC 1.57N Thru-Hole T/R RoHS: Compliant Min Qty: 463 Package Multiple: 1 Americas - 2108
  • 463 $0.1636
  • 511 $0.1441
  • 1,000 $0.1250
  • 2,000 $0.1029
$0.1029 / $0.1636 Buy Now
DISTI # 2-1437565-6
TME Microswitch TACT, SPST-NO, Pos: 2, 0.05A/24VDC, THT, none, 1.6N Min Qty: 10 1060
  • 10 $0.1130
  • 100 $0.0920
  • 500 $0.0820
  • 1,000 $0.0720
$0.0720 / $0.1130 Buy Now
DISTI # AMP2-1437565-6
Interstate Connecting Components FSM2JRT=PUSHBUTTONS SWITCH 0
  • 30,000 $0.0724
  • 104,000 $0.0619
$0.0619 / $0.0724 Buy Now
DISTI # 2-1437565-6
Avnet Abacus Switch Tactile OFF ON Round Button PC Pins 005A 12VDC 157N ThruHole Radial Tape (Alt: 2-1437565-6) RoHS: Compliant Min Qty: 3000 Package Multiple: 1000 Lead time: 24 Weeks, 0 Days Abacus - 0
Buy Now
DISTI # 2-1437565-6
Avnet Abacus Switch Tactile OFF ON Round Button PC Pins 005A 12VDC 157N ThruHole Radial Tape (Alt: 2-1437565-6) RoHS: Compliant Min Qty: 30000 Package Multiple: 10000 Lead time: 24 Weeks, 0 Days Abacus - 0
Buy Now
Master Electronics FSM2JRT=PUSHBUTTONS SWITCH RoHS: Compliant 19000 In Stock
  • 1,000 $0.0888
  • 3,000 $0.0710
  • 8,000 $0.0681
  • 25,000 $0.0647
  • 50,000 $0.0593
  • 100,000 $0.0532
  • 150,000 $0.0524
  • 250,000 $0.0516
$0.0516 / $0.0888 Buy Now

Part Details for 2-1437565-6

2-1437565-6 Part Data Attributes

Parametric Data
2-1437565-6 TE Connectivity
Buy Now Datasheet
Compare Parts:
2-1437565-6 TE Connectivity KEYPAD SWITCH, SPST, MOMENTARY-TACTILE, 0.05A, 24VDC, 2.06N, THROUGH HOLE-STRAIGHT, ROHS COMPLIANT
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer TE CONNECTIVITY LTD
Package Description ROHS COMPLIANT
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8536.50.90.40
Samacsys Manufacturer TE Connectivity
Actuator Color NATURAL
Actuator Length 0.028 inch
Actuator Material POLYACETAL
Body Breadth 6.19 mm
Body Color BLACK
Body Height 3.6 mm
Body Length or Diameter 6.19 mm
Center Contact Plating SILVER
Circuit Configuration 1X1
Contact Current(AC)-Max 0.05 A
Contact Current(DC)-Max 0.05 A
Contact (DC) Max Rating R Load .05A@24VDC
Contact Voltage(DC)-Max 24 V
Electrical Life 100000 Cycle(s)
End Contact Material COPPER ALLOY
Housing Material POLYAMIDE
Mounting Feature PANEL MOUNT
Number of Switches 1
Operating Force-Max 2.205 N
Operating Temperature-Max 85 °C
Operating Temperature-Min -35 °C
Packing Method TR
Surface Mount NO
Switch Action MOMENTARY
Switch Function SPST
Switch Type KEYPAD SWITCH
Termination Type SOLDER

Alternate Parts for 2-1437565-6

This table gives cross-reference parts and alternative options found for 2-1437565-6. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of 2-1437565-6, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
KSA0M311LFT ITT Interconnect Solutions Check for Price Keypad Switch, 1 Switches, SPST, Momentary-tactile, 0.05A, 32VDC, 1.3N, Solder Terminal, Through Hole-straight, ROHS COMPLIANT 2-1437565-6 vs KSA0M311LFT
FSM17JL TE Connectivity Check for Price KEYPAD SWITCH, SPST, MOMENTARY-TACTILE, 0.05A, 12VDC, 1.47N, THROUGH HOLE-STRAIGHT 2-1437565-6 vs FSM17JL
FSM14JL TE Connectivity Check for Price KEYPAD SWITCH, SPST, MOMENTARY-TACTILE, 0.05A, 12VDC, 1.47N, THROUGH HOLE-STRAIGHT 2-1437565-6 vs FSM14JL
1BT003-2712L-001 Foxconn Check for Price Keypad Switch, 1 Switches, SPST, Momentary-tactile, 0.05A, 1.27N, Solder Terminal, Through Hole-straight, LEAD FREE 2-1437565-6 vs 1BT003-2712L-001
PHAP3301A APEM Inc Check for Price Keypad Switch, 1 Switches, SPST, Momentary-tactile, 0.05A, 12VDC, 2.1N, Solder Terminal, Through Hole-straight 2-1437565-6 vs PHAP3301A
KSM0631C Hokuriku Electric Industry Co Ltd Check for Price Keypad Switch, 1 Switches, SPST, Momentary-tactile, 0.05A, 24VDC, 3.24N, Solder Terminal, Through Hole-right Angle 2-1437565-6 vs KSM0631C
KT11B0CM ITT Interconnect Solutions Check for Price Keypad Switch, 1 Switches, SPST, Momentary, 0.02A, 50VDC, 4 PCB Hole Cnt, Solder Terminal, Through Hole-straight 2-1437565-6 vs KT11B0CM
FSM9JL TE Connectivity Check for Price KEYPAD SWITCH, SPST, MOMENTARY-TACTILE, 0.05A, 12VDC, 1.47N, THROUGH HOLE-STRAIGHT 2-1437565-6 vs FSM9JL
KT11P2CM C&K Check for Price KEYPAD SWITCH, SPST, MOMENTARY, 0.02A, 50VDC, THROUGH HOLE-STRAIGHT 2-1437565-6 vs KT11P2CM
FSM10JLH TE Connectivity Check for Price KEYPAD SWITCH, SPST, MOMENTARY, 0.05A, 24VDC, 1.47N, THROUGH HOLE-STRAIGHT, ROHS COMPLIANT 2-1437565-6 vs FSM10JLH
