1N5251B-TR Information
1N5251B-TR by Vishay Intertechnologies is a Zener Diode.
Zener Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for 1N5251B-TR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
33C2879
|
Newark | Zener Diode, single, Two Terminal,22V V(Z),5%,do-35 Rohs Compliant: Yes |Vishay 1N5251B-TR RoHS: Compliant Min Qty: 30000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.0290 | Buy Now |
|
DISTI #
1N5251B-TR
|
Avnet Americas | ZENER DIODE DO35 - Tape and Reel (Alt: 1N5251B-TR) RoHS: Compliant Min Qty: 30000 Package Multiple: 30000 Lead time: 9 Weeks, 0 Days Container: Reel | 0 |
|
$0.0293 / $0.0299 | Buy Now |
|
DISTI #
78-1N5251B
|
Mouser Electronics | Zener Diodes 22 Volt 0.5 Watt RoHS: Compliant | 108743 |
|
$0.0260 / $0.1400 | Buy Now |
|
|
Bristol Electronics | 20000 |
|
RFQ | ||
|
|
Quest Components | 16000 |
|
$0.0192 / $0.1440 | Buy Now | |
|
DISTI #
1N5251B-TR
|
TTI | Zener Diodes 22 Volt 0.5 Watt pbFree: Pb-Free Min Qty: 30000 Package Multiple: 10000 Container: Reel | Americas - 0 |
|
$0.0210 / $0.0227 | Buy Now |
Part Details for 1N5251B-TR
1N5251B-TR CAD Models
1N5251B-TR Part Data Attributes
|
|
1N5251B-TR
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
1N5251B-TR
Vishay Intertechnologies
Zener Diode, 22V V(Z), 5%, 0.5W, Silicon, Unidirectional, DO-204AH, DO-35, 2 PIN
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | DO-35, 2 PIN | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 9 Weeks | |
| Samacsys Manufacturer | Vishay | |
| Case Connection | ISOLATED | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | ZENER DIODE | |
| Dynamic Impedance-Max | 29 Ω | |
| JEDEC-95 Code | DO-204AH | |
| JESD-30 Code | O-PALF-W2 | |
| JESD-609 Code | e2 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 175 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | ROUND | |
| Package Style | LONG FORM | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity | UNIDIRECTIONAL | |
| Power Dissipation-Max | 0.5 W | |
| Qualification Status | Not Qualified | |
| Reference Standard | AEC-Q101 | |
| Reference Voltage-Nom | 22 V | |
| Surface Mount | NO | |
| Technology | ZENER | |
| Terminal Finish | Tin/Silver (Sn96.5Ag3.5) | |
| Terminal Form | WIRE | |
| Terminal Position | AXIAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Voltage Tol-Max | 5% | |
| Working Test Current | 5.6 mA |
1N5251B-TR Frequently Asked Questions (FAQ)
-
The recommended soldering temperature for the 1N5251B-TR is between 250°C to 260°C for a maximum of 10 seconds.
-
Yes, the 1N5251B-TR is a high-speed switching diode with a fast recovery time of 4 ns, making it suitable for high-frequency applications up to 1 GHz.
-
The maximum allowable power dissipation for the 1N5251B-TR is 500 mW at a temperature of 25°C.
-
No, the 1N5251B-TR is not a radiation-hardened device. It is not designed to withstand high levels of radiation and should not be used in radiation-intensive applications.
-
The equivalent series resistance (ESR) of the 1N5251B-TR is typically around 1.5 ohms.
