1N4448WS Information
1N4448WS by onsemi is a Rectifier Diode.
Rectifier Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for 1N4448WS
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
08AK7788
|
Newark | Small Signal Diode/ Reel |Onsemi 1N4448WS RoHS: Not Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 2109 |
|
$0.0370 / $0.1000 | Buy Now |
|
DISTI #
09N9938
|
Newark | Small Signal Diode, Single, 75 V, 150 Ma, 1 V, 4 Ns |Onsemi 1N4448WS RoHS: Not Compliant Min Qty: 15000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.0190 / $0.0270 | Buy Now |
|
DISTI #
1N4448WSFSCT-ND
|
DigiKey | DIODE STANDARD 75V 150MA SOD323F Min Qty: 1 Lead time: 22 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
36619 In Stock |
|
$0.0164 / $0.0212 | Buy Now |
|
DISTI #
08AK7788
|
Avnet Americas | Diode Small Signal Switching 100V 150mA 2-Pin SOD-323F T/R - Product that comes on tape, but is not reeled (Alt: 08AK7788) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 35 Weeks, 5 Days Container: Ammo Pack | 0 |
|
$0.0420 / $0.1250 | Buy Now |
|
DISTI #
512-1N4448WS
|
Mouser Electronics | Small Signal Switching Diodes Small Signal Diode RoHS: Compliant | 87061 |
|
$0.0170 / $0.1000 | Buy Now |
|
DISTI #
V79:2366_17797126
|
Arrow Electronics | Diode Small Signal Switching 75V 0.15A 2-Pin SOD-323FL T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 36 Weeks Date Code: 2151 | Americas - 483127 |
|
$0.0140 / $0.0550 | Buy Now |
|
DISTI #
V72:2272_06296901
|
Arrow Electronics | Diode Small Signal Switching 75V 0.15A 2-Pin SOD-323FL T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 22 Weeks Date Code: 2333 Container: Cut Strips | Americas - 35163 |
|
$0.0556 / $0.0910 | Buy Now |
|
DISTI #
E02:0323_00840346
|
Arrow Electronics | Diode Small Signal Switching 75V 0.15A 2-Pin SOD-323FL T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 22 Weeks | Europe - 21000 |
|
$0.0159 | Buy Now |
|
DISTI #
V36:1790_06296901
|
Arrow Electronics | Diode Small Signal Switching 75V 0.15A 2-Pin SOD-323FL T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 22 Weeks Date Code: 2151 | Americas - 15000 |
|
$0.0144 / $0.0210 | Buy Now |
|
|
Future Electronics | 1N4448WS Series 150 mA 75 V 200 mW Surface Mount Small Signal Diode - SOD-323F RoHS: Compliant pbFree: Yes Min Qty: 3000 Package Multiple: 3000 Lead time: 24 Weeks Container: Reel | 21000Reel |
|
$0.0154 / $0.0168 | Buy Now |
Part Details for 1N4448WS
1N4448WS CAD Models
1N4448WS Part Data Attributes
|
|
1N4448WS
onsemi
Buy Now
Datasheet
|
Compare Parts:
1N4448WS
onsemi
Small Signal Diode, SOD-323FL, 3000-REEL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | SOD-323FL | |
| Package Description | SC-90, 2 PIN | |
| Manufacturer Package Code | 477AB | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.70 | |
| Factory Lead Time | 35 Weeks, 5 Days | |
| Samacsys Manufacturer | onsemi | |
| Application | GENERAL PURPOSE | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | RECTIFIER DIODE | |
| Forward Voltage-Max (VF) | 0.72 V | |
| JESD-30 Code | R-PDSO-F2 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Non-rep Pk Forward Current-Max | 4 A | |
| Number of Elements | 1 | |
| Number of Phases | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Output Current-Max | 0.15 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Rep Pk Reverse Voltage-Max | 100 V | |
| Reverse Recovery Time-Max | 0.004 µs | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) - annealed | |
| Terminal Form | FLAT | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 |
