Part Details for 1N4148WS-V-GS08 by Vishay Intertechnologies
Results Overview of 1N4148WS-V-GS08 by Vishay Intertechnologies
- Distributor Offerings: (4 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
1N4148WS-V-GS08 Information
1N4148WS-V-GS08 by Vishay Intertechnologies is a Rectifier Diode.
Rectifier Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| 1N4148WS | Toshiba Electronic Devices & Storage Corporation | Switching Diode, 100 V, 0.25 A, 2 in 1, SOD-323 |
Price & Stock for 1N4148WS-V-GS08
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
55R1218
|
Newark | Switching Diode, 100V 150Ma Sod-323, Full Reel, Diode Configuration:Single, Repetitive Peak Reverse Voltage:100V, Average Forward Current:150Ma, Forward Voltage Max:1.2V, Reverse Recovery Time:4Ns, Forward Surge Current:350Ma Rohs Compliant: Yes |Vishay 1N4148WS-V-GS08 RoHS: Compliant Min Qty: 15000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
Buy Now | |
|
|
Bristol Electronics | 3766 |
|
RFQ | ||
|
DISTI #
1N4148WS-V-GS08
|
EBV Elektronik | Diode Small Signal Switching 100V 150mA 2Pin SOD323 TR (Alt: 1N4148WS-V-GS08) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 143 Weeks, 0 Days | EBV - 0 |
|
Buy Now | |
|
|
Vyrian | Diodes | 1204 |
|
RFQ |
Part Details for 1N4148WS-V-GS08
1N4148WS-V-GS08 CAD Models
1N4148WS-V-GS08 Part Data Attributes
|
|
1N4148WS-V-GS08
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
1N4148WS-V-GS08
Vishay Intertechnologies
Rectifier Diode, 1 Phase, 1 Element, 0.15A, 100V V(RRM), Silicon, ROHS COMPLIANT, PLASTIC PACKAGE-2
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | ROHS COMPLIANT, PLASTIC PACKAGE-2 | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | Vishay | |
| Application | GENERAL PURPOSE | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | RECTIFIER DIODE | |
| Forward Voltage-Max (VF) | 1 V | |
| JESD-30 Code | R-PDSO-G2 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Non-rep Pk Forward Current-Max | 0.35 A | |
| Number of Elements | 1 | |
| Number of Phases | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Output Current-Max | 0.15 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Power Dissipation-Max | 0.2 W | |
| Qualification Status | Not Qualified | |
| Reference Standard | AEC-Q101 | |
| Rep Pk Reverse Voltage-Max | 100 V | |
| Reverse Recovery Time-Max | 0.004 µs | |
| Surface Mount | YES | |
| Terminal Finish | MATTE TIN | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 10 |
1N4148WS-V-GS08 Frequently Asked Questions (FAQ)
-
The recommended soldering temperature for the 1N4148WS-V-GS08 is 260°C (500°F) for a maximum of 10 seconds.
-
Yes, the 1N4148WS-V-GS08 is suitable for high-frequency applications due to its low capacitance and fast switching time.
-
Yes, the 1N4148WS-V-GS08 can be used in switching power supplies due to its high switching speed and low voltage drop.
-
No, the 1N4148WS-V-GS08 is not radiation-hardened. It is not designed for use in high-radiation environments.
-
The maximum allowable voltage for the 1N4148WS-V-GS08 is 100 V, as specified in the datasheet.
