1N4148W-7-F Information

1N4148W-7-F by SPC Multicomp is a Rectifier Diode.
Rectifier Diodes are under the broader part category of Diodes.

A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.

Available Datasheets

Part # Manufacturer Description Datasheet
1N4148WS Toshiba Electronic Devices & Storage Corporation Switching Diode, 100 V, 0.25 A, 2 in 1, SOD-323
1N4148WT Toshiba Electronic Devices & Storage Corporation Switching Diode, 100 V, 0.25 A, SOD-523
