1N4007-TP-HF by: Micro Commercial Components

Rectifier Diode, 1 Element, 1A, 1000V V(RRM), Silicon, DO-41,

Part Details for 1N4007-TP-HF by Micro Commercial Components

Results Overview of 1N4007-TP-HF by Micro Commercial Components

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Space Technology Aerospace and Defense Energy and Power Systems

1N4007-TP-HF Information

1N4007-TP-HF by Micro Commercial Components is a Rectifier Diode.
Rectifier Diodes are under the broader part category of Diodes.

A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.

Price & Stock for 1N4007-TP-HF

Part # Distributor Description Stock Price Buy
DISTI # 353-1N4007-TP-HF-ND
DigiKey DIODE STANDARD 1000V 1A DO41 Min Qty: 5000 Lead time: 16 Weeks Container: Bulk Temporarily Out of Stock
  • 5,000 $0.0355
$0.0355 Buy Now
DISTI # 833-1N4007-TP-HF
Mouser Electronics Rectifiers RoHS: Compliant 0
  • 1 $0.2100
  • 10 $0.1460
  • 100 $0.0720
  • 1,000 $0.0420
  • 5,000 $0.0350
  • 10,000 $0.0320
  • 25,000 $0.0310
$0.0310 / $0.2100 Order Now
Cytech Systems Limited   1000
RFQ
Vyrian Diodes 1074
RFQ

Part Details for 1N4007-TP-HF

1N4007-TP-HF CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

1N4007-TP-HF Part Data Attributes

Parametric Data
1N4007-TP-HF Micro Commercial Components
Buy Now Datasheet
Compare Parts:
1N4007-TP-HF Micro Commercial Components Rectifier Diode, 1 Element, 1A, 1000V V(RRM), Silicon, DO-41,
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer MICRO COMMERCIAL COMPONENTS CORP
Package Description O-PALF-W2
Reach Compliance Code not_compliant
ECCN Code EAR99
HTS Code 8541.10.00.80
Samacsys Manufacturer MCC
Application GENERAL PURPOSE
Case Connection ISOLATED
Configuration SINGLE
Diode Element Material SILICON
Diode Type RECTIFIER DIODE
Forward Voltage-Max (VF) 1 V
JEDEC-95 Code DO-41
JESD-30 Code O-PALF-W2
JESD-609 Code e3
Moisture Sensitivity Level 1
Non-rep Pk Forward Current-Max 30 A
Number of Elements 1
Number of Phases 1
Number of Terminals 2
Operating Temperature-Max 150 °C
Operating Temperature-Min -55 °C
Output Current-Max 1 A
Package Body Material PLASTIC/EPOXY
Package Shape ROUND
Package Style LONG FORM
Peak Reflow Temperature (Cel) 260
Rep Pk Reverse Voltage-Max 1000 V
Reverse Current-Max 5 µA
Reverse Recovery Time-Max 2 µs
Surface Mount NO
Terminal Finish Matte Tin (Sn)
Terminal Form WIRE
Terminal Position AXIAL
Time@Peak Reflow Temperature-Max (s) 5
