1977223-1 Information
1977223-1 by TE Connectivity is a Pushbutton Switch.
Pushbutton Switches are under the broader part category of Switches.
Electrical switches are binary devices that control the flow of current in a circuit by either allowing or preventing the flow of electrons. Read more about Switches on our Switches part category page.
Price & Stock for 1977223-1
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
69AH4453
|
Newark | Tactile Switch, 0.05A, 24Vdc, 100Gf, Smd Rohs Compliant: Yes |Alcoswitch Te Connectivity 1977223-1 RoHS: Compliant Min Qty: 10 Package Multiple: 1 Date Code: 0 Container: Bulk | 15112 |
|
$0.1910 / $0.2790 | Buy Now |
|
DISTI #
1977223-1-ND
|
DigiKey | SWITCH TACTILE SPST-NO 0.05A 24V Min Qty: 1 Lead time: 14 Weeks Container: Bag |
27283 In Stock |
|
$0.2055 / $0.4500 | Buy Now |
|
DISTI #
1977223-1
|
Avnet Americas | Switch Tactile OFF (ON) SPST Round Button Gull Wing 0.05A 24VDC 1000000Cycle 0.98N SMD Loose Piece - Bulk (Alt: 1977223-1) RoHS: Compliant Min Qty: 30000 Package Multiple: 30000 Lead time: 19 Weeks, 5 Days Container: Bulk | 0 |
|
$0.1171 / $0.1384 | Buy Now |
|
DISTI #
506-1977223-1
|
Mouser Electronics | Tactile Switches 6MM ACTSMT 100gf TACT SWITCH RoHS: Compliant | 22744 |
|
$0.1760 / $0.3400 | Buy Now |
|
DISTI #
72034353
|
RS | Switch, Fsm2Jsmls=6Mm Tact Switch, Smt 100Gf Min Qty: 30000 Package Multiple: 1 Container: Bulk | 0 |
|
$0.7000 / $0.7800 | RFQ |
|
DISTI #
AMP1977223-1
|
Heilind Electronics | FSM2JSMLS=6MM TACT SWITCH SMT 100GF | Americas - 0 in Stock |
|
$0.1709 / $0.1735 | Buy Now |
|
|
Onlinecomponents.com | FSM2JSMLS=6MM TACT SWITCH, SMT 100gf RoHS: Compliant |
2739 In Stock |
|
$0.1275 / $0.1803 | Buy Now |
|
DISTI #
88148323
|
Verical | Switch Tactile OFF (ON) SPST Round Button Gull Wing 0.05A 24VDC 1000000Cycles 0.98N SMD Loose RoHS: Compliant Min Qty: 750 Package Multiple: 1 Date Code: 2127 | Americas - 30000 |
|
$0.2101 / $0.2424 | Buy Now |
|
DISTI #
1977223-1
|
TME | Microswitch TACT, SPST-NO, Pos: 2, 0.05A/24VDC, SMT, none, 1N, FSM Min Qty: 30000 | 0 |
|
$0.1340 | RFQ |
|
DISTI #
AMP1977223-1
|
Interstate Connecting Components | FSM2JSMLS=6MM TACT SWITCH SMT 100GF | 0 |
|
$0.1709 / $0.1735 | Buy Now |
Part Details for 1977223-1
1977223-1 CAD Models
1977223-1 Part Data Attributes
|
|
1977223-1
TE Connectivity
Buy Now
Datasheet
|
Compare Parts:
1977223-1
TE Connectivity
Pushbutton Switch, SPST, Momentary, 0.05A, 24VDC, Solder Terminal, Panel Mount
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TE CONNECTIVITY LTD | |
| Package Description | ROHS COMPLIANT | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 19 Weeks, 5 Days | |
| Samacsys Manufacturer | TE Connectivity | |
| Actuator Color | BLUE | |
| Actuator Length | 0.028 inch | |
| Actuator Material | NYLON | |
| Body Breadth | 6 mm | |
| Body Color | BROWN | |
| Body Height | 4.29 mm | |
| Body Length or Diameter | 6 mm | |
| Center Contact Plating | SILVER | |
| Contact Current(AC)-Max | 0.05 A | |
| Contact Current(DC)-Max | 0.05 A | |
| Contact (DC) Max Rating R Load | 0.05A@24VDC | |
| Contact Voltage(DC)-Max | 24 V | |
| Electrical Life | 1000000 Cycle(s) | |
| End Contact Material | COPPER ALLOY | |
| Housing Material | POLYPHENYLENE SULPHIDE | |
| Illumination | NON-ILLUMINATED | |
| Mounting Feature | PANEL MOUNT | |
| Operating Force-Max | 0.98 N | |
| Operating Temperature-Max | 105 °C | |
| Operating Temperature-Min | -40 °C | |
| Packing Method | BULK | |
| Surface Mount | NO | |
| Switch Action | MOMENTARY | |
| Switch Function | SPST | |
| Switch Type | MINIATURE SWITCH | |
| Termination Type | SOLDER |
