10129383-910001ALF Information
10129383-910001ALF by Amphenol Communications Solutions is a Header and Edge Type Connector.
Headers and Edge Type Connectors are under the broader part category of Connectors.
Connectors are devices that join electrical termination points to form circuits. With various types designed for specific functions like data, power, or signal transmission, choosing the right connector is essential for compatibility and device performance. Read more about Connectors on our Connectors part category page.
Price & Stock for 10129383-910001ALF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
82AH5178
|
Newark | Btb Conn, Header, 10Pos, 2Row, 2.54Mm Rohs Compliant: Yes |Amphenol Communications Solutions 10129383-910001ALF RoHS: Compliant Min Qty: 10 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 4485 |
|
$0.3260 / $0.3980 | Buy Now |
|
|
Future Electronics | Conn Unshrouded Header 10 POS 2.54mm Solder ST SMD RoHS: Compliant pbFree: Yes Min Qty: 370 Package Multiple: 370 Lead time: 19 Weeks Container: Reel | 4810Reel |
|
$0.2050 / $0.2150 | Buy Now |
|
|
Onlinecomponents.com | Header Dr Vt SMT 2X5-10129383-910001ALF | Amphenol Fci (amphenol Cs) 10129383910001ALF RoHS: Compliant |
1714 In Stock |
|
$0.2087 / $0.2560 | Buy Now |
|
|
Future Electronics | Conn Unshrouded Header 10 POS 2.54mm Solder ST SMD Min Qty: 370 Package Multiple: 370 |
4810 null |
|
$0.2050 / $0.2150 | Buy Now |
|
|
LCSC | SMDP2.54mm Pin Headers ROHS | 15 |
|
$0.4768 / $0.5055 | Buy Now |
|
|
Master Electronics | Header Dr Vt SMT 2X5-10129383-910001ALF | Amphenol Fci (amphenol Cs) 10129383910001ALF RoHS: Compliant |
1714 In Stock |
|
$0.2087 / $0.2560 | Buy Now |
|
|
Vyrian | Connectors | 3643 |
|
RFQ |
Part Details for 10129383-910001ALF
10129383-910001ALF CAD Models
10129383-910001ALF Part Data Attributes
|
|
10129383-910001ALF
Amphenol Communications Solutions
Buy Now
Datasheet
|
Compare Parts:
10129383-910001ALF
Amphenol Communications Solutions
EconoStik™, Board to Board connector, Unshrouded Vertical Header, Surface Mount, Double Row, 10 Positions, 2.54 mm (0.100in) Pitch.
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | AMPHENOL COMMUNICATIONS SOLUTIONS | |
| Pin Count | 10 | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | Amphenol Communications Solutions | |
| Body Breadth | 0.19 inch | |
| Body Depth | 0.15 inch | |
| Body Length | 1 inch | |
| Connector Type | BOARD CONNECTOR | |
| Contact Finish Mating | NOT SPECIFIED | |
| Contact Gender | MALE | |
| Contact Material | NOT SPECIFIED | |
| Contact Pattern | RECTANGULAR | |
| Contact Resistance | 20 mΩ | |
| Contact Style | SQ PIN-SKT | |
| Dielectric Withstanding Voltage | 1500VAC V | |
| Durability | 50 Cycles | |
| Filter Feature | NO | |
| Insulation Resistance | 1000000000 Ω | |
| Insulator Color | BLACK | |
| Insulator Material | POLYETHYLENE | |
| Mating Contact Pitch | 0.1 inch | |
| Mating Contact Row Spacing | 0.1 inch | |
| Mixed Contacts | NO | |
| Mounting Option 1 | LOCKING | |
| Mounting Style | STRAIGHT | |
| Mounting Type | BOARD | |
| Number Of Connectors | ONE | |
| Number Of PCB Rows | 2 | |
| Number of Rows Loaded | 2 | |
| Operating Temperature-Max | 105 °C | |
| Operating Temperature-Min | -55 °C | |
| Option | GENERAL PURPOSE | |
| PCB Contact Pattern | RECTANGULAR | |
| PCB Contact Row Spacing | 5.46 mm | |
| Plating Thickness | FLASH inch | |
| Polarization Key | POLARIZED HOUSING | |
| Rated Current (Signal) | 3 A | |
| Reference Standard | UL | |
| Terminal Pitch | 2.54 mm | |
| Termination Type | SURFACE MOUNT | |
| Total Number of Contacts | 10 | |
| UL Flammability Code | 94V-0 |
