1.5SMBJ36CA Information
1.5SMBJ36CA by Bourns Inc is a Transient Suppressor.
Transient Suppressors are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for 1.5SMBJ36CA
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
26AK6965
|
Newark | Dio Tvs Vrwm 36V 1500W Bidir Smb /Tape & Reel - 13" Reel |Bourns 1.5SMBJ36CA RoHS: Not Compliant Min Qty: 12000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.3110 / $0.3740 | Buy Now |
|
DISTI #
118-1.5SMBJ36CACT-ND
|
DigiKey | TVS DIODE 36VWM 58.1VC DO214AA Min Qty: 1 Lead time: 16 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
12747 In Stock |
|
$0.2938 / $0.3120 | Buy Now |
|
DISTI #
1.5SMBJ36CA
|
Avnet Americas | Diode TVS Single Bi-Dir 36V 1500W 2-Pin DO-214AA (SMB) T/R - Tape and Reel (Alt: 1.5SMBJ36CA) RoHS: Not Compliant Min Qty: 12000 Package Multiple: 3000 Lead time: 16 Weeks, 0 Days Container: Reel | 0 |
|
$0.2813 / $0.3145 | Buy Now |
|
DISTI #
652-1.5SMBJ36CA
|
Mouser Electronics | ESD Protection Diodes / TVS Diodes DIO TVS VRWM 36V 1500W BIDIR SMB RoHS: Compliant | 11842 |
|
$0.2930 / $0.8800 | Buy Now |
|
DISTI #
73793238
|
RS | DIO TVS VRWM 36V 1500W BIDIR SMBTR13,Tape & Reel - 13 reel Min Qty: 12000 Package Multiple: 1 Lead time: 18 Weeks, 0 Days Container: Bulk | 0 |
|
$0.7500 / $0.8900 | RFQ |
|
|
Onlinecomponents.com | TVS Diode - 36Vrwm -1500W - Bidirectionsl - SMB RoHS: Compliant | 0 |
|
$0.2917 / $0.7990 | Buy Now |
|
DISTI #
1.5SMBJ36CA
|
TTI | ESD Protection Diodes / TVS Diodes DIO TVS VRWM 36V 1500W BIDIR SMB RoHS: Compliant pbFree: Pb-Free Min Qty: 12000 Package Multiple: 3000 Container: Reel | Americas - 0 |
|
$0.3330 | Buy Now |
|
DISTI #
1.5SMBJ36CA-BOU
|
TME | Diode: TVS, 1.5kW, 40÷44.2V, 25.9A, bidirectional, ±5%, SMB, 1.5SMBJ Min Qty: 1 | 0 |
|
$0.3900 / $0.6550 | RFQ |
|
DISTI #
1.5SMBJ36CA
|
Avnet Abacus | Diode TVS Single BiDir 36V 1500W 2Pin DO214AA SMB TR - Tape and Reel (Alt: 1.5SMBJ36CA) RoHS: Compliant Min Qty: 12000 Package Multiple: 3000 Lead time: 17 Weeks, 0 Days Container: Reel | Abacus - 0 |
|
Buy Now | |
|
|
Master Electronics | TVS Diode - 36Vrwm -1500W - Bidirectionsl - SMB RoHS: Compliant | 0 |
|
$0.2917 / $0.7990 | Buy Now |
Part Details for 1.5SMBJ36CA
1.5SMBJ36CA CAD Models
1.5SMBJ36CA Part Data Attributes
|
|
1.5SMBJ36CA
Bourns Inc
Buy Now
Datasheet
|
Compare Parts:
1.5SMBJ36CA
Bourns Inc
Trans Voltage Suppressor Diode, 1500W, 36V V(RWM), Bidirectional, 1 Element, Silicon, DO-214AA, SMB, 2 PIN
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | BOURNS INC | |
| Package Description | SMB, 2 PIN | |
| Reach Compliance Code | not_compliant | |
| Factory Lead Time | 16 Weeks | |
| Samacsys Manufacturer | Bourns | |
| Additional Feature | PRSM-MIN | |
| Breakdown Voltage-Max | 44.2 V | |
| Breakdown Voltage-Min | 40 V | |
| Breakdown Voltage-Nom | 42.1 V | |
| Clamping Voltage-Max | 58.1 V | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | TRANS VOLTAGE SUPPRESSOR DIODE | |
| JEDEC-95 Code | DO-214AA | |
| JESD-30 Code | R-PDSO-C2 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Non-rep Peak Rev Power Dis-Max | 1500 W | |
| Number of Elements | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Polarity | BIDIRECTIONAL | |
| Reference Standard | IEC-61000-4-2, 4-4, 4-5; UL RECOGNIZED | |
| Rep Pk Reverse Voltage-Max | 36 V | |
| Reverse Current-Max | 1 µA | |
| Reverse Test Voltage | 36 V | |
| Surface Mount | YES | |
| Technology | AVALANCHE | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | C BEND | |
| Terminal Position | DUAL |
