0ZCH0200FF2E Information
0ZCH0200FF2E by Bel Fuse is a Non-linear Resistor.
Non-linear Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for 0ZCH0200FF2E
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
58AC4654
|
Newark | T&r |Bel Fuse 0ZCH0200FF2E RoHS: Not Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
$0.1290 | Buy Now |
|
DISTI #
5923-0ZCH0200FF2ECT-ND
|
DigiKey | PTC RESET FUSE 6V 2A 1210 Min Qty: 1 Lead time: 12 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
15904 In Stock |
|
$0.1106 / $0.3600 | Buy Now |
|
DISTI #
0ZCH0200FF2E
|
Avnet Americas | SMD Resettable Fuse, PPTC, 1210 (3225 Metric), 0ZCH, 6 VDC, 2 A, 4 A, 1 s - Tape and Reel (Alt: 0ZCH0200FF2E) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 11 Weeks, 0 Days Container: Reel | 0 |
|
$0.1182 | Buy Now |
|
|
Onlinecomponents.com | PTC Resettable Fuse 2A(hold) 4A(trip) 6VDC 100A 0.8W 1s 0.015Ohm SMD Solder Pad 1210 T/R Automotive RoHS: Compliant |
3000 In Stock |
|
$0.0963 / $0.1243 | Buy Now |
|
DISTI #
0ZCH0200FF2E
|
IBS Electronics | 0ZCH0200FF2E by BEL FUSE is a 1210 SMT PPTC resettable fuse with 2A hold, 4A trip, 6VDC, 100A max current, 0.8W power, 0.015 ohm resistance, and SMD solder pad, ideal for automotive applications. Min Qty: 3000 Package Multiple: 1 | 3000 |
|
$0.1252 / $0.1616 | Buy Now |
|
DISTI #
0ZCH0200FF2E
|
Avnet Abacus | SMD Resettable Fuse PPTC 1210 3225 Metric 0ZCH 6 VDC 2 A 4 A 1 s - Tape and Reel (Alt: 0ZCH0200FF2E) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 19 Weeks, 0 Days Container: Reel | Abacus - 0 |
|
Buy Now | |
|
|
Master Electronics | PTC Resettable Fuse 2A(hold) 4A(trip) 6VDC 100A 0.8W 1s 0.015Ohm SMD Solder Pad 1210 T/R Automotive RoHS: Compliant |
3000 In Stock |
|
$0.0963 / $0.1243 | Buy Now |
Part Details for 0ZCH0200FF2E
0ZCH0200FF2E CAD Models
0ZCH0200FF2E Part Data Attributes
|
|
0ZCH0200FF2E
Bel Fuse
Buy Now
Datasheet
|
Compare Parts:
0ZCH0200FF2E
Bel Fuse
PTC Thermistor
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | BEL FUSE INC | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 11 Weeks | |
| Samacsys Manufacturer | BelFuse | |
| Additional Feature | MINIMUM RESISTANCE IS 0.015 OHMS | |
| JESD-609 Code | e3 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Height | 1.4 mm | |
| Package Length | 3.43 mm | |
| Package Style | SMT | |
| Package Width | 2.8 mm | |
| Packing Method | TR, 7 INCH | |
| Rated Power Dissipation (P) | 0.8 W | |
| Reference Standard | CUL, TUV, UL | |
| Resistor Type | PTC THERMISTOR | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Placement | DUAL ENDED | |
| Terminal Shape | WRAPAROUND | |
| Thermistor Application | TEMPERATURE SENSING | |
| Working Voltage | 6 V |
0ZCH0200FF2E Frequently Asked Questions (FAQ)
-
The recommended PCB footprint for the 0ZCH0200FF2E is a rectangular pad with dimensions of 2.5mm x 1.25mm, with a 0.5mm radius corner. The pad should be centered on the component and have a 0.2mm clearance around the perimeter.
-
To ensure reliable soldering of the 0ZCH0200FF2E, use a soldering iron with a temperature of 250°C to 270°C, and apply a small amount of solder paste to the PCB pad. Use a gentle touch and avoid applying excessive pressure, which can damage the component.
-
The maximum operating temperature range for the 0ZCH0200FF2E is -40°C to 125°C. However, it's recommended to operate the component within a temperature range of -20°C to 100°C for optimal performance and reliability.
-
Yes, the 0ZCH0200FF2E is designed to withstand high-vibration environments. However, it's recommended to follow proper mounting and soldering techniques to ensure the component remains securely attached to the PCB.
-
The recommended storage condition for the 0ZCH0200FF2E is in a dry, cool place with a temperature range of 20°C to 30°C and humidity below 60%. Avoid storing the component in direct sunlight or near sources of moisture.
