09663517512 Information
09663517512 by HARTING Technology Group is a D Type Connector.
D Type Connectors are under the broader part category of Connectors.
Connectors are devices that join electrical termination points to form circuits. With various types designed for specific functions like data, power, or signal transmission, choosing the right connector is essential for compatibility and device performance. Read more about Connectors on our Connectors part category page.
Price & Stock for 09663517512
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
17AC1053
|
Newark | D-Sub Conn, Rcpt, 25Pos, Th, No. Of Contacts:25Contacts, Gender:Receptacle, Contact Termination Type:Solder, D Sub Shell Size:Db, Product Range:-, Connector Body Material:Steel Body, Contact Material:Copper Alloy, Contact Plating:-, Rohs Compliant: Yes |Harting 09663517512 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk | 18 |
|
$4.6200 / $6.9100 | Buy Now |
|
DISTI #
1195-5026-ND
|
DigiKey | CONN D-SUB RCPT 25POS VERT SLDR Min Qty: 1 Lead time: 10 Weeks Container: Bulk |
29 In Stock |
|
$3.7196 / $6.4600 | Buy Now |
|
DISTI #
617-09663517512
|
Mouser Electronics | D-Sub Standard Connectors DSUB SV FEM SSDP STR 25P PL3 GC 4-40 RoHS: Compliant | 47 |
|
$3.7100 / $6.4600 | Buy Now |
|
DISTI #
V36:1790_06773960
|
Arrow Electronics | Conn D-Sub F 25 POS 1.38mm Solder ST Thru-Hole 25 Terminal 1 Port RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 10 Weeks Date Code: 2408 | Americas - 30 |
|
$3.4790 / $4.7650 | Buy Now |
|
DISTI #
70739726
|
RS | Connectors, D-Sub, Standard, DSUB SV FEM SSDP STR 25P PL3 GC 4-40 Min Qty: 100 Package Multiple: 1 Lead time: 8 Weeks, 0 Days Container: Bulk | 0 |
|
$5.1900 / $6.4900 | RFQ |
|
DISTI #
HRT09663517512
|
Heilind Electronics | Americas - 0 in Stock |
|
$4.2923 / $4.6936 | Buy Now | |
|
DISTI #
78395487
|
Verical | Conn D-Sub F 25 POS 1.38mm Solder ST Thru-Hole 25 Terminal 1 Port RoHS: Compliant Min Qty: 2 Package Multiple: 1 Date Code: 2408 | Americas - 30 |
|
$3.4790 / $4.7650 | Buy Now |
Part Details for 09663517512
09663517512 CAD Models
09663517512 Part Data Attributes
|
|
09663517512
HARTING Technology Group
Buy Now
Datasheet
|
Compare Parts:
09663517512
HARTING Technology Group
D Subminiature Connector, 25 Contact(s), Female, Solder Terminal,
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | HARTING ELECTRONICS GMBH & CO KG | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | HARTING | |
| Additional Feature | STANDARDS: DIN 41652; IEC 60807 | |
| Connector Type | D SUBMINIATURE CONNECTOR | |
| Contact Finish Mating | NOT SPECIFIED | |
| Contact Finish Termination | NOT APPLICABLE | |
| Contact Gender | FEMALE | |
| Contact Material | NOT SPECIFIED | |
| DIN Conformance | YES | |
| Empty Shell | NO | |
| Filter Feature | NO | |
| IEC Conformance | YES | |
| Insulator Material | GLASS FILLED POLYBUTYLENE TEREPHTHALATE/POLYESTER | |
| MIL Conformance | NO | |
| Mating Information | MULTIPLE MATING PARTS AVAILABLE | |
| Mixed Contacts | NO | |
| Mounting Type | BOARD AND PANEL | |
| Option | GENERAL PURPOSE | |
| Shell Material | STEEL | |
| Shell Size | 3/B | |
| Termination Type | SOLDER | |
| Total Number of Contacts | 25 | |
| UL Flammability Code | 94V-0 |
