09062486834 Information
09062486834 by HARTING Technology Group is a Power Connector.
Power Connectors are under the broader part category of Connectors.
Connectors are devices that join electrical termination points to form circuits. With various types designed for specific functions like data, power, or signal transmission, choosing the right connector is essential for compatibility and device performance. Read more about Connectors on our Connectors part category page.
Price & Stock for 09062486834
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
1195-1333-ND
|
DigiKey | CONN DIN RCPT 48POS Min Qty: 1 Lead time: 8 Weeks Container: Bulk |
272 In Stock |
|
$5.6822 / $9.2500 | Buy Now |
|
DISTI #
617-09-06-248-6834
|
Mouser Electronics | DIN 41612 Connectors 48P 6A FEMALE STRT RoHS: Compliant | 595 |
|
$5.6800 / $8.8000 | Buy Now |
|
DISTI #
E02:0323_00177947
|
Arrow Electronics | Conn DIN 41612 F 48 POS 5.08mm Solder ST Thru-Hole RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 1 Weeks Date Code: 2446 | Europe - 135 |
|
$5.2049 / $7.6271 | Buy Now |
|
DISTI #
HRT09062486834
|
Heilind Electronics | DIN-POWER FLOW048FS-4,5C1-2 | Americas - 0 in Stock |
|
$6.7344 / $8.6200 | Buy Now |
|
DISTI #
86938139
|
Verical | Conn DIN 41612 F 48 POS 5.08mm Solder ST Thru-Hole RoHS: Compliant Min Qty: 2 Package Multiple: 1 Date Code: 2446 | Americas - 134 |
|
$6.4556 / $10.0016 | Buy Now |
|
|
Quest Components | 48 CONTACT(S), FEMALE, POWER CONNECTOR, SOLDER | 81 |
|
$11.5440 / $14.0400 | Buy Now |
|
|
Quest Components | 48 CONTACT(S), FEMALE, POWER CONNECTOR, SOLDER | 12 |
|
$6.0863 / $12.1725 | Buy Now |
|
|
Quest Components | 48 CONTACT(S), FEMALE, POWER CONNECTOR, SOLDER | 10 |
|
$13.9300 / $15.6713 | Buy Now |
|
DISTI #
09062486834
|
TTI | DIN 41612 Connectors 48P 6A FEMALE STRT RoHS: Compliant pbFree: Pb-Free Min Qty: 1 Package Multiple: 1 Container: Bulk |
Americas - 17 In Stock |
|
$5.6000 / $7.2300 | Buy Now |
|
DISTI #
09062486834
|
TME | Connector: DIN 41612, plug, female, PIN: 48, straight, THT, 6A Min Qty: 20 | 0 |
|
$5.3700 / $5.5900 | RFQ |
Part Details for 09062486834
09062486834 CAD Models
09062486834 Part Data Attributes
|
|
09062486834
HARTING Technology Group
Buy Now
Datasheet
|
Compare Parts:
09062486834
HARTING Technology Group
Rectangular Power Connector, 48 Contact(s), Female, Solder Terminal, Plug,
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | HARTING ELECTRONICS GMBH & CO KG | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8536.69.40.30 | |
| Samacsys Manufacturer | HARTING | |
| Board Mounting Option | HOLE 0.11 | |
| Body Breadth | 0.58 inch | |
| Body Depth | 0.398 inch | |
| Body Length | 3.74 inch | |
| Connector Type | BOARD EURO CONNECTOR | |
| Contact Finish Mating | NOT SPECIFIED | |
| Contact Finish Termination | GOLD OVER NICKEL | |
| Contact Gender | FEMALE | |
| Contact Material | NOT SPECIFIED | |
| Contact Pattern | RECTANGULAR | |
| Contact Resistance | 15 mΩ | |
| Contact Style | RND PIN-SKT | |
| DIN Conformance | YES | |
| Durability | 400 Cycles | |
| Filter Feature | NO | |
| IEC Conformance | NO | |
| Insertion Force-Max | 75 N | |
| Insulation Resistance | 1000000000000 Ω | |
| Insulator Color | GRAY | |
| Insulator Material | GLASS FILLED POLYETHYLENE | |
| JESD-609 Code | e4 | |
| MIL Conformance | NO | |
| Mating Contact Pitch | 0.15 inch | |
| Mating Contact Row Spacing | 0.15 inch | |
| Mixed Contacts | NO | |
| Mounting Option 1 | LOCKING | |
| Mounting Style | STRAIGHT | |
| Mounting Type | BOARD | |
| Name of Rows Loaded | B,D,Z | |
| Number Of Connectors | ONE | |
| Number Of PCB Rows | 3 | |
| Number of Rows Loaded | 3 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -55 °C | |
| Option | GENERAL PURPOSE | |
| PCB Contact Pattern | RECTANGULAR | |
| PCB Contact Row Spacing | 3.81 mm | |
| Polarization Key | POLARIZED | |
| Rated Current (Power) | 6 A | |
| Reference Standard | UL | |
| Terminal Length | 0.177 inch | |
| Terminal Pitch | 3.81 mm | |
| Termination Type | SOLDER | |
| Total Number of Contacts | 48 | |
| UL Flammability Code | 94V-0 | |
| Withdrawl Force-Min | 75 N |
