Part Details for 0603L100SLYR by Littelfuse Inc
Results Overview of 0603L100SLYR by Littelfuse Inc
- Distributor Offerings: (18 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Environmental Monitoring
Industrial Automation
0603L100SLYR Information
0603L100SLYR by Littelfuse Inc is a Non-linear Resistor.
Non-linear Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for 0603L100SLYR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
69W6439
|
Newark | Ptc Resettable Fuse, 6Vdc, 0603, Pptc Case Style:0603 (1608 Metric), Product Range:Polyswitch Low Rho Series, Voltage Rating:6Vdc, Holding Current:1A, Trip Current:1.8A, Time To Trip:0.3S, Current Rating Max:50A Rohs Compliant: Yes |Littelfuse 0603L100SLYR RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 2927 |
|
$0.6480 | Buy Now |
|
DISTI #
44W7450
|
Newark | Ptc Resettable Fuse, 6Vdc, 0603, Pptc Case Style:0603 (1608 Metric), Product Range:Polyswitch Low Rho Series, Voltage Rating:6Vdc, Holding Current:1A, Trip Current:1.8A, Time To Trip:0.3S, Current Rating Max:50A Rohs Compliant: Yes |Littelfuse 0603L100SLYR RoHS: Compliant Min Qty: 4000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.7470 / $0.8050 | Buy Now |
|
DISTI #
F5761CT-ND
|
DigiKey | PTC RESET FUSE 6V 1A 0603 Min Qty: 1 Lead time: 13 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
12924 In Stock |
|
$0.7288 / $1.7800 | Buy Now |
|
DISTI #
576-0603L100SLYR
|
Mouser Electronics | Resettable Fuses - PPTC 6V POLYFUSE 0603 LoRho SL 1A RoHS: Compliant | 20413 |
|
$0.7290 / $1.5200 | Buy Now |
|
DISTI #
V72:2272_06410740
|
Arrow Electronics | PTC Resettable Fuse 1A(hold) 1.8A(trip) 6VDC 50A 0.6W 0.3s 0.04Ohm SMD Solder Pad 0603 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 13 Weeks Container: Cut Strips | Americas - 1710 |
|
$0.7476 / $1.0553 | Buy Now |
|
DISTI #
72244492
|
RS | Fuse, Resettable, 603L Series, Polymeric, Surface Mount, 6V, 1A Min Qty: 4000 Package Multiple: 1 Container: Bulk | 0 |
|
$2.8900 / $3.6100 | RFQ |
|
|
Onlinecomponents.com | PTC Resetable Fuse - 1000mA Hold - 1800mA Trip - 6VDC max - SMD 0603 - Tape&Reel RoHS: Compliant |
2599 Partner Stock |
|
$1.4100 / $1.9900 | Buy Now |
|
DISTI #
23832797
|
Verical | PTC Resettable Fuse 1A(hold) 1.8A(trip) 6VDC 50A 0.6W 0.3s 0.04Ohm SMD Solder Pad 0603 T/R RoHS: Compliant Min Qty: 78 Package Multiple: 1 | Americas - 2927 |
|
$1.7444 | Buy Now |
|
DISTI #
58772254
|
Verical | PTC Resettable Fuse 1A(hold) 1.8A(trip) 6VDC 50A 0.6W 0.3s 0.04Ohm SMD Solder Pad 0603 T/R RoHS: Compliant Min Qty: 8 Package Multiple: 1 Date Code: 2119 | Americas - 1710 |
|
$0.7476 / $1.0553 | Buy Now |
|
|
Bristol Electronics | Min Qty: 4 | 61 |
|
$1.0312 / $1.6500 | Buy Now |
Part Details for 0603L100SLYR
0603L100SLYR CAD Models
0603L100SLYR Part Data Attributes
|
|
0603L100SLYR
Littelfuse Inc
Buy Now
Datasheet
|
Compare Parts:
0603L100SLYR
Littelfuse Inc
PTC Resettable Fuse, Surface Mount, CHIP, 0603, HALOGEN FREE AND ROHS COMPLIANT
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | LITTELFUSE INC | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8533.40.80.70 | |
| Samacsys Manufacturer | LITTELFUSE | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Height | 0.75 mm | |
| Package Length | 1.8 mm | |
| Package Shape | RECTANGULAR PACKAGE | |
| Package Style | SMT | |
| Package Width | 1 mm | |
| Packing Method | TR, 7 INCH | |
| Reference Standard | CUL; TUV; UL | |
| Resistance | 0.04 Ω | |
| Resistor Type | PTC RESETTABLE FUSE | |
| Surface Mount | YES | |
| Terminal Placement | DUAL ENDED | |
| Terminal Shape | WRAPAROUND | |
| Thermistor Application | OVERCURRENT PROTECTION | |
| Working Voltage | 6 V |
